Designed for 4K or 8K setups, the AVR-X1700H delivers the ultimate 3D audio home theater/gaming experiences and supports the latest HDMI specifications.

Powerful, Discrete 7-channel Amplifier

Delivers maximum performance and 80W per channel to provide the classic and dynamic Denon sound experience.

Advanced 8K HDMI Video with eARC Support

Three 8K inputs support the latest HDMI specifications-8K/60Hz, select 4K/120Hz pass-through, VRR, Dolby Vision™, HDR10+, ALLM.

Full 3D Audio Support with Virtual Surround Sound

Enjoy immersive 3D audio with Dolby Atmos®, Dolby Atmos Height Virtualization Technology, DTS:X®, and DTS Virtual:X™.

Enhanced Gaming Experiences

Variable Refresh Rate (VRR) and Auto Low Latency Mode (ALLM) care for amazing imaging as well as reduced lag and latency.

Built-in Bluetooth, Wi-Fi

Dual-antenna transceiver for robust Bluetooth and Wi-Fi streaming even in congested environments.

Defining Audio Excellence

With a deep legacy of firsts and amazing sound, Denon is the defining audio company of Japan.

Wireless Music Streaming

Enjoy music services like Spotify®, Pandora, Amazon Music HD, and more with HEOS® Built-in.

Audyssey Room Correction

Precisely analyzes the output of each speaker to optimize every channel's performance.

Specifications:

• Number of Power Amps: 7
• Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive): 80 W
• Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 120 W
• Power Output (6 ohm, 1 kHz, 10% 1ch Drive): 175 W

Multichannel Surround:

• DTS HD Master / DTS: X: Yes / Yes
• DTS Neo:X / DTS Neural: X: No / Yes
• DTS Virtual: X: Yes
• Dolby TrueHD / Dolby Atmos: Yes / Yes
• Dolby ProLogic II / Dolby Surround: No / Yes
• Dolby Height Virtualization: Yes
• Multichannel Stereo: Yes
• Dialog Enhancer: Yes
• Max Number of Processing (Preamp) Channels: 7.1

Sound Enhancements:

• Discrete Power Amplifier: 7
• Audyssey: MultEQ XT
• Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
• Audyssey APP Support: Yes
• Speaker Setup Presets: 2
• Compressed Audio Restorer: Yes

Network:

• HEOS Multiroom and Streaming: Yes
• Lossy Formats: MP3 / WMA / AAC: Yes / Yes / Yes
• Lossless Formats: FLAC / ALAC / WAV: Yes / Yes / Yes
• DSD Audio Streaming: up to DSD5.6
• FLAC HD 192/24: Yes
• WAV 192/24: Yes
• ALAC 192/24: Yes
• Gapless playback: Yes (FLAC, WAV, ALAC, DSD)
• AirPlay 2: Yes
• Roon Tested: Yes
• Internet Radio: TuneIn
• Spotify Connect* / Tidal* / Deezer* / others *: Yes / Yes / Yes / Yes
• Amazon Prime Music* / Pandora*: Yes / Yes
• Compatible with Remote APP for Smart Phones: Android / iOS
• Compatible with Remote APP for Tablets: Android / iOS / Amazon Kindle
• Ethernet Ports: Yes
• Wi-Fi: Yes
• Bluetooth: Yes
• Bluetooth Headphone transmission: Yes

HDMI:

• HDMI Inputs: Back / Front: 6 (3x 8K) / 0
• HDCP2.3 support: Yes
• HDMI Outputs: Main / Zone: 1 / No
• HDMI max Resolution (8k / 4k): 8k/60 - 4k/120
• HDMI to HDMI Scaling: up to 8K 60/50
• HDMI: 8K / 4K / CEC / eARC: Yes / Yes / Yes / Yes
• HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG: Yes / Yes / Yes / Yes
• HDMI: ALLM / QMS / QFT / VRR: Yes / Yes / Yes / Yes
• HDMI pass-though in standby mode: Yes

Multi-Room CI:

• HEOS Multiroom integrated: Yes
• TV Sound grouping: Yes
• Multiroom zones: 2
• Main room multichanel audio - Zone stereo downmix: Yes
• Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: Yes (2ch) / Yes (2ch) / Yes / Yes
• Zone Audio Output: Speaker / Preout: Yes / Yes
• Webbrowser Setup: Yes
• IP Control / RS232 Control / Web Control / App Control: Yes / No / Yes / Yes
• Remote In / Out: 1 / No

Others:

• Voice Control - Works with Amazon Alexa: Yes
• Voice Control - Google Assist / Apple Siri: Yes / Yes
• Auto Speaker Setup by Microphone: Audyssey MultEQ XT
• FL Display: 1 line
• Graphic User Interface - GUI: Hybrid GUI
• GUI Languages: 3
• Setup Assistant: Yes
• Quick Select Plus / Quick Select: Yes / No
• Firmware Update by: Network / USB: Yes / Yes
• Variable Cross Over: Yes
• Optimized Bass Redirection: Yes
• ECO Mode: Yes
• Auto Power Off: Yes
• Sleep Timer: Yes

Inputs Outputs:

• Composite In / Out: 2 / 1
• Component In / Out: No / No
• HDMI In / Out: 6 / 1
• Multi-room Video Out: Video / HDMI: No / No
• Analogue In/out: 2 / No
• Phono (MM) In: Yes
• Digital In: Optical / Coaxial: 2 / 1
• Multi-room Out: Analog / Digital: Yes / No
• Multichannel Preout: Yes (0.2)
• Subwoofer Out: 2
• Speaker Terminal: Gold Plated Screw / Regular Screw: No / Yes
• Number of Speaker Terminals: 7
• Speaker A / B: assignable
• Bi-amp Drive: assignable
• Multi-Room Speaker Terminal: assignable
• Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB: No / No / No / No / Yes
• USB Audio / Made for iPod / Made for iPhone: Yes / AirPlay / AirPlay
• Tuner: FM / AM: Yes / Yes

General:

• System Remote Control: RC-1244
• Pre-programmed / Learnable / LCD Display: No / No / No
• Power Consumption in W: 430
• Power Consumption No-Sound (ECO On / Off) in W: 29 W / 39 W
• Dimensions (W x D x H): 434 x 339 x 151 mm
• Standby Consumption in W: 0.1
• CEC Standby Consumption in W: 0.5
• Network Control On Consumption in W: 2.0
• Maximum Dimensions w/ Antenna (W x D x H): 434 x 339 x 151 mm
• Weight in kg: 8.6
• Maximum Dimensions
• Antenna: Horizontal: (W x D x H) in Inches: 17.1 x 13.3 x 6
• Antenna: Vertical: (W x D x H) in Inches
• W/O Antenna: (W x D x H) in Inches: ( 17.1 x 13.3 x 8.5)
• Weight in LBS: 18.96
