Onkyo TX-NR787 9.2-Channel Network Dolby Atmos 5.2.4 A/V Receiver (2018 Model)

Secure One-Page Checkout

$999.99

Onkyo Authorised
Onkyo TX-NR787 Available 999.99
UPC : 889951001348 5% Price Promise
Warranty : 1yr Manufacturer 14 Day Money Back
Shipping : FREE in Canada Ships out in 5 Days



Instant rebate with code THUNDER until May 22.


Onkyo TX-NR787

With nine channels of high-current amplification, the TX-NR787 fully unlocks DTS:X® and Dolby Atmos® movie soundtracks with a 5.2.4-channel speaker layout at THX® Certified Select™ theater-reference volume. Alternatively, you can also use the extra channels to drive speakers in Zone 2 and Zone 3. Dual-band Wi-Fi® links the receiver to your desired multi-room platform via DTS Play-Fi® technology, FlareConnect™, or Chromecast built-in that also works with the Google Assistant. AirPlay and Bluetooth® wireless technologies are built in, and onboard streaming services include Amazon Music, TIDAL, Spotify, and TuneIn. Future-ready, the receiver has HDMI® supporting 4K/60p, BT.2020, HDR10, Dolby Vision™, and HLG video pass-through. This muscular A/V hub waits to enrich your entertainment life.

Features

  • THX® Certified Select™ Reference Sound
  • 100 W/Ch (8 Ohms), 220 W/Ch (6 Ohms)
  • 5.2.4 or 7.2.2-Ch Dolby Atmos® & DTS:X®
  • HDMI® 7 In (1 front) / Main Out and Sub Out
  • 4K/60 Hz, HDR10, HLG, Dolby Vision™, BT.2020, and HDCP 2.2
  • Powered Zone 2/3 Speaker Outputs and Zone 2 Line Output
  • Chromecast built-in and Works with the Google Assistant
  • 384 kHz/32-bit DAC and VLSC™ Filtering for Superior Clarity
  • Amazon Music, Spotify®, TIDAL, Deezer, Pandora®, and TuneIn

Amplifier

  • # Channels : 9.2
  • Power Watts/Ch (8 Ohms 20-20kHz, 2 Channels Driven, FTC) : 100 Watts, 0.08% THD
  • Power Watts/Ch (6 Ohms 1kHz, 1 Channel Driven) : 220 Watts, 10% THD
  • Dynamic Audio Amplification : YES (for Clear and Realistic Sound)
  • H.C.P.S. (High Current Power Supply) : YES
  • Non-Phase Shift Amplifier : YES
  • THX Certified : YES
  • Continuous 6 Ohms Rated : YES
  • Certified 4 Ohms Performance : YES
  • Discrete Output Stage Circuitry : YES
  • Amplifier Design : Linear Class A/B
  • Independent Block Construction (Amp/Preprocessor) : NA
  • Independent Power Supply : NA
  • Bi-amp Capability For Front : YES

Processing

  • Dolby Atmos : YES
  • 32-Bit Digital Signal Processing Engine : YES
  • Dolby Decoder : Dolby Atmos, True HD, Dolby Surround
  • DTS:X : YES
  • DTS Decoder : DTS:X, DTS-HD Master Audio, Neural:X
  • ONKYO GAME Surround Modes : YES (Rock, Sports, Action, RPG)
  • VLSC for Noiseless Audio Processing : YES (Fronts)
  • THX Processing Mode : YES
  • CinemaFILTER : NA
  • AccuEQ Room Calibration : YES (w/ AccuReflex)
  • Phase-Matching Bass Boost : YES
  • Direct/Pure Mode : YES / NA
  • Pure Direct Analog Path Mode : NA
  • Advanced Music Optimizer : YES
  • 384K/32 Bit DACs : YES
  • 192K/24 Bit DACs : NA

Connectivity

  • Analog Audio IN : 6
  • Phono Input : YES
  • Digital Audio IN (OPT/COAX) : 2 / 1
  • Composite Video I/O : 2 / 0
  • Component Video I/O : 2 / 0
  • Front Panel HDMI : YES
  • Front-Panel A/V : 1 (Analog)
  • USB Input : YES (Rear)
  • HDMI I/O : 7 / 2 (Main/Sub)
  • HDMI 4K/60 Hz- Capable HDMI Terminals : YES
  • HDCP 2.2 Copy-Protection Compatibility : YES
  • HDMI Support for High Dynamic Range : YES
  • HDMI Support for 3D, Audio Return Channel and CEC : YES
  • Dolby Vision, HDR10, HLG, BT.2020 Support : YES
  • HDMI Support for Deep Color, x.v.Color, LipSync : YES
  • HDMI Support for DVD-Audio, SACD, Multichannel PCM : YES
  • Analog To HDMI Upconversion : YES
  • 4K Passthrough : YES
  • Analog Pre-Outs : Subwoofer (x2)
  • Speaker A/+B : NA
  • Powered Zone 2 : YES
  • Powered Zone 3 : YES
  • Zone 2 Line Out : YES
  • Zone 2 Video Out : NA
  • Zone 2 Digital to Analog Audio Conversion : YES (Net/SPDIF)
  • Zone 3 Digital to Analog Audio Conversion : YES (Net)
  • Zone 3 Line Out : NA
  • Whole House Mode : NA
  • FireConnect Multi-room Audio : YES
  • Airplay : YES
  • Chromecast built-in support : YES
  • Supports Onkyo Remote App : YES
  • Internet Radio Capable : YES (TuneIn)
  • Spotify Connect Support : YES
  • Tidal : YES
  • Amazon Music : YES (accessible via Onkyo Music Control app)
  • Streaming Audio From PC / Network : YES
  • Hi-Res Streaming Audio Formats : YES
  • Streaming Audio From USB memory : YES
  • Wireless Network : IEEE 802.11 a/b/g/n 5 Ghz / 2.4 Ghz
  • Bluetooth : YES (Built-in)

Integration Access

  • RS-232 : YES
  • IR Input : YES
  • IR Output : NA
  • Ethernet : YES
  • ONKYO-RI System Control : NA
  • RIHD (Remote Interactive Over HDMI) : YES
  • 12V Trigger : YES

Miscellaneous

  • Pre-Programmed Remote : NA
  • Hybrid Standby Function : YES
  • Smart Grid-Ready : YES
  • Auto Speaker Calibration W/Mic. : AccuEQ w/ AccuReflex
  • OSD Out : YES
  • Solid Aluminum Front : NA
  • Transparent High-Grade Speaker Terminals : NA
  • Detachable AC Cord : YES
  • Warranty : 2 YEARS

Amplifier Section

  • Power Output
  • All Channels : 100 W/Ch (8 Ohms, 20 Hz–20 kHz, 0.08% THD, 2 Channels Driven, FTC)
    220 W/Ch (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)
  • Dynamic Power : 250 W (3 Ohms, Front)
    220 W (4 Ohms, Front)
    130 W (8 Ohms, Front)
  • THD+N (Total Harmonic Distortion + Noise) : 0.08% (20 Hz–20 kHz, Half Power)
  • Damping Factor : NA
  • Input Sensitivity and Impedance : 200 mV/47 k-ohms (Line/Unbalanced)
    3.5 mV/47 k-ohms (Phono/MM)
  • Rated RCA Output Level and Impedance : 200 mV/2.3 k-ohms (Zone 2 Line Out)
    1 V/470 ohms (Subwoofer Pre Out)
  • Maximum RCA Output Level and Impedance : NA
  • Phono Overload : 70 mV (MM, 1 kHz, 0.5%)
  • Frequency Response : 10 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
  • Tone Control : ±10 dB, 20 Hz (Bass)
    ±10 dB, 20 kHz (Treble)
  • Signal-to-Noise Ratio : 106 dB (Line, IHF-A)
    80 dB (Phono, IHF-A)
  • Speaker Impedance : 4 ohms–16 ohms

Video Section

  • Input Sensitivity/Output Level and Impedance : NA
  • Video : 1.0 Vp–p/75 Ohms (Component Y)
    0.7 Vp–p/75 Ohms (Component PB/CB, PR/CR)
    1.0 Vp–p/75 Ohms (Composite)
  • Component Video Frequency Response : +0 dB, -3 dB

Tuner Section

  • Tuning Frequency Range
    • FM : 87.5 MHz–1070.9 MHz
    • AM : 530 kHz–1,710 kHz
    • FM/AM Preset Memory : 40 stations
  • General
    • Power Supply : AC 120 V~, 60 Hz
    • Power Consumption : 750 W
    • No-Sound Power Consumption : 70 W
    • Standby Power Consumption : 0.15 W
    • Dimensions (W x H x D) : 17 1/8" x 6 13/16" x 14 15/16" (435 x 173.5 x 379.5 mm)
    • Weight : 23.8 lbs (10.8 kg)
  • Carton
    • Dimensions (W x H x D) : 22 7/16" x 11 5/16" x 18 7/16"
      (570 x 288 x 468 mm)
    • Weight : 29.8 lbs (13.5 kg)
    • UPC Code >(B) : 889951001348
