Turn turn turn

What better way to celebrate the 50th Anniversary of the Summer of Love than with the certifiably far-out TN-420 turntable?

Beneath the groovy exterior, this 2-speed turntable combines a high density MDF base with an expertly machined aluminum platter to deliver incredible resonance rejection, speed control and audio fidelity. And for easy connection to virtually any audio system, the TN-420 features switchable Phono / Line level outputs on RCA connectors and a digital output on USB for easy connection to a Mac or PC for playback and archiving of your favorite LPs.

A fusion of unique appearance and excellent sound.

The eye-catching appearance of the TN-420-TD is achieved through a modern hydro-graphics printing process and adds a groovy touch to any music room. And just below this colorful is a high density MDF cabinet designed to minimize unwanted resonance during playback.

The high inertia aluminum die-cast platter is driven by a high-torque DC motor with durable Neoprene® rubber belt to achieve stable rotation. In addtition, highly accurate rotation of this platter is maintained by a polished spindle (machined from a stainless steel block) and a durable bronze spindle holder.

Enjoy vinyl playback with any amplifier. The TN-420-TD supports both both Phono and Line output, and allows you to enjoy your favorite albums on virtually any music system.

An On-board Analog-to-Digital converter from Texas Instruments allows you to transfer music via USB to your PC and to create CD-quality backups of your favotire albums. In addition, a pair of gold-plated RCA connectors are employed for reliable connection to either the Line or Phono inputs of your receveiver and amplifier.

To ensure years of reliable performance, Gold-plated terminals on the head shell connectors prevent oxidation over time.

Due to increased mass, an S-shaped tone arm is employed for high tracking accuracy. Coupled with an adjustable anti-skating mechanism, the TN-420-TD will help you to get up and rocking in no time.

2-speed Turntable including 33-1/3 and 45 RPM for LP/EP record playback

Perfect for albums or singles, the TN-420-TD features both 33-1/3 and 45 RPM playback and a manual tone-arm lifter for complete control of your music experience.

The TN-420-TD comes with an audio-technica vm-type cartridge, which carries a reputation for accuracy, clarity and detail.

Features:

• 2-speed Turntable including 33-1/3 and 45 RPM for LP/EP record playback
• Unique Tie-Dye finish
• Built-in phono equalizer amplifier for MM type cartridge (Line/Phono output switchable)
• USB digital output for transferring music from vinyl to Mac or PC
• Belt-drive turntable for enhanced speed control and consistency
• Manual arm lifter for direct tone arm control
• Static balanced S-shaped Tone Arm
• Replaceable Head shell
• Anti-skating system prevents tracking errors
• Heavy-weight Aluminum Die-cast Platter
• Japan made mm-type cartridge (audio-technica AT95E) included
• Corrosion resistant gold-plated terminals

Specifications:

Turntable section:

• Drive System: Belt Drive
• Motor: DC Motor
• Speed: 33 1/3 RPM, 45 RPM
• Rotation Speed Variation: +/–2%
• Wow and Flutter: 0.2%
• Signal-to-Noise Ratio: 67dB or higher (A-weighted, 20kHz LPF) 60dB or higher (unweighted, 20kHz LPF)
• Platter: Aluminum Die-cast
• Diameter of Platter: 12", 30cm

Tonearm section:

• Type: Static Balance, S-shaped
• Effective Arm Length: 8.8", 223mm
• Stylus Pressure Range: 0 to 5g
• Supported Cartridge Weight: 3.5 to 6.5g
• Anti-skating Adjustment: Supported

Cartridge section:

• Type: MM type (audio-technica AT95E factory installed)
• Stylus Shape: Elliptical
• Stylus Construction: Bonded Round Shank
• Mount: Half inch
• Frequency Response: 20Hz to 20kHz
• Channel Separation: 20dB at 1kHz
• Channel Balance: 2.0dB
• Tracking Force: 1.5 to 2.5g
• Vertical Tracking Angle: 20 degrees
• Supported Load Impedance: 47k ohms
• Output Voltage: 3.5mV (1kHz, 5cm/sec.)
• Stylus Pressure: 2.0g +/–0.5g
• Cartridge Weight: 5.7g +/–0.5g
• Head-shell Weight: 10g (including Screws, Nuts and Wires)
• Replacement Stylus: audio-technica ATN95E

Phono Equalizer Amplifier:

• Type of Amplifier: MM type (On/Thru switchable)

Analog Output:

• Connector: RCA Pin jack (Gold-plated)
• Output Voltage: Phono/Line switchable
• Phono Output: 4.5mV +/–3dB
• Line Output: 120mV (–13dBV)

USB Output section:

• Connector: USB B type
• Output Signal: PCM 48kHz/16-bit
• Windows 7
• Windows 8
• Windows 8.1
• Windows 10
• OS X Lion (10.7)
• OS X Mountain Lion (10.8)
• OS X Mavericks (10.9)
• OS X Yosemite (10.10)
• OS X El Capitan (10.11)
• macOS Sierra (10.12)

Power:

• AC 100 to 240V, 50/60Hz

Power Consumption:

• 1.5W (less than 0.5W at Standby)

Overall Dimensions (W x H x D):

• 16.5" x 4.6" x 14.0" 420 x 117 x 356 mm

Weight:

• Approx. 10.8 lbs. 4.9 kg

Accessories:

• Felt Mat, EP Adapter, Counter Weight, Head-shell (audio-technica AT95E), Platter, Dust Cover, Rubber Feet for Dust Cover x2, Hinge x2, RCA Audio Cable, AC Adapter (GPE053A-120050-1), Owner's Manual
