True Diversity Tuner

The 5000 series tuners are designed to deliver outstanding performance , stability and reliability. A wide choice of channels can be obtained by the using PLL-synthesized oscillators enabling the selection of channels freely without interference.

Additionally, the 5000 series provide significantly less potential for noise caused by antenna changeover , by employing true diversity and space diversity methods. Two-line LCD display enables faster meter reading. Remaining battery power indication. PLL synthesis is incorporated to generate highly accurate frequency output signals that help achieve better overall system performance. For further performance enhancement, a TOA diversity system eliminates dead spots and provides more stable signal reception. Noise reduction is improved with a squelch function (carrier, noise, tone), and a compounder function minimising ambient noise. For easier operation, a Channel Check function simplifies channel setting operations on microphones using multiple channels simultaneously.

• Compact half-rack size
• Scanner function
• Transmitter battery status display
• 64 selectable channels
• True diversity reception
• Two detachable antennas
• Optional Rack-Mount Kits: 3
• MB-WT3 (One WT-5800/WT-5805)
• MB-WT4 (Two WT-5800/WT-5805)
• Front panel: Output volume control
• Power On/Off switch
• LEDs: Antenna A/B, Battery, Peak and Power
• Front Panel: LCD, RF and AF Metering
• Channel display and adjust
• Squelch adjust and bypass
• Adjustable brightness
• Rear panel
• Outputs: XLR-M (mic) and 1/4" phone jack (line)
• Mix-In 1/4" jack (line)
• Antenna inputs (2)
• Antenna loop outputs (2)

Specifications:

• Frequency Range: 576 - 698 MHz, UHF
• Diversity System: True diversity
• Antenna Input: 75 ohm, BNC
• Antenna Output: 75 ohm, BNC (Gain 0dB)
• Tone Frequency: 32.768 kHz
• S/N Ratio: 110dB or more (A-weight, unbalanced output)
• Dimensions: 210(W) x 44(H) x 205.1(D) mm (8.27" x 1.73" x 8.07")
• Weight: 700 g (1.54lb)
