Exclusive Protect or Disconnect™ Circuitry

Safeguards equipment against all surges. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to connected equipment.

Signal Perfect™ Circuitry

Optimized phone line surge protection circuitry ensures a clean, clear signal. It features solid-state SIDACtor® and autor-resetting PTCR's for maximum protection and reliability.

Features:

• One 15 Amp AC Outlet
• One 20 Amp AC Outlet
• Protect-or-Disconnect™ Circuitry
• Convenient security feature; attach the protector to your equipment’s power cords.
• Three diagnostic lights indicate wiring integrity and protection status.
• Space-saving design plugs directly into wall outlet.
• Convenient security feature; attach the protector to your equipment’s power cords.
• Versatile outlet orientation accommodates the widest range of plug styles including transformers and right angle plugs.

Specifications:

General:

• Family: Direct Plug Ins
• Line Voltage: 120 (Volts)
• Number of Outlets: 2
• Outlet Descriptions: One 15 Amp AC Outlet and One 20 Amp AC Outlet, both filtered and surge protected
• Compliance: C-UL (UL standard #1449)
• Dimensions: 3.12" W X 5.5" D X 2" H
• Weight: 0.75 lbs

AC Protection:

• AC Protection Technology:
• Protect or Disconnect
• L-N, L-G, N-G Protection Modes
• Thermal Fusing
• Maximum Current Rating: 20 (Amps)
• Initial Clamping Level: 200V Peak

Filtration:

• Filtration Technology: RFI/EMI Filtration
• Filtration Rating: 50 dB @ 100 kHz - 1 MHz
