VR 1510S

No matter how you plan on connecting your HD cable set-top box, Blu-ray™ player or media consoles, you want the best picture quality and sound. And simple connections. The Harman Kardon® AVR 1510S is a 5.1-channel, 375-watt, networked audio/video receiver that gives you four 3D-ready HDMI® inputs – plug them in once to experience all your entertainment with precision and clarity. With DLNA® 1.5, you can stream audio from your networked devices, and built-in vTuner™ Internet radio connects you to a whole world of online audio entertainment. And thanks to HARMAN GreenEdge™ certification, it’s lightweight. You’ll experience true Harman Kardon power, only now in a more environmentally friendly form factor.

Five 75-watt-per-channel amplifiers with high-performance digital power supply

The AVR 1510 high-performance, audio/video receiver pumps out 75 watts per channel to power a full 5.1-channel surround sound system. It can also connect to powered subwoofers to provide enhanced low-frequency performance for your music, movies, HDTV shows, sports and video games. While the amplifier retains the time-tested Harman Kardon high-current-capacity (HCC), ultrawide-bandwidth amplifier design to ensure the most accurate, dynamic sound with enhanced clarity and realism, even at the highest listening levels, a digitally based power supply gives the amplifier all the muscle it needs without the weight of traditional power-supply designs and their heavy transformers. The net result is a great-sounding product in a smaller form factor that is friendly to the environment.

General Specifications

• Multichannel Power (all channels driven) : 75W per channel, two channels driven @ 6/8 ohms, 1kSHz, <0.1% THD
• Transient intermodulation distortion (TIM): : Unmeasurable
• Power Requirement : 120V AC / 60Hz
• Power Consumption (full power/idle) : <0.5W (standby); 410W maximum

Audio Specifications

• Frequency Range (kHz) : 520kHz – 1510kHz
• Frequency Range (MHz) : 87.5MHz – 108.0MHz
• Stereo Power : 75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.1% THD
• Input Sensitivity/Impedence : 250mV/27k ohms
• Signal-to-noise Ratio (IHF-A) (dB) : 75dB
• Surround system adjacent-channel separation: : Dolby Pro Logic®/DPLII: 40dB; Dolby Digital: 55dB; DTS®: 55dB
• Frequency Response : 10Hz – 130kHz (+0dB/–3dB)
• High Instantaneous Current Capability : ±25 amps
• Slew Rate : 40V/sec
• Usable Sensitivity (IHF) : 1.3µV/13.2dBf
• Signal-to-Noise Ratio (Mono/Stereo dB) : 70dB/68dB
• Distortion (Mono/Stereo) : 0.2%/0.3%
• Stereo Separation @ 1kHz (dB) : 40dB
• Selectivity (±400kHz): : 70dB
• Signal-to-Noise Ratio (dB) : 38dB
• Usable Sensitivity (Loop) : 375µV
• Distortion (1kHz, 50% mod): : 1.0%
• Selectivity (±10kHz): : 30dB
• Input Level/Impedence (ohm) : 1Vp-p/75 ohms
• Output Level/Impedence (ohm) : 1Vp-p/75 ohms

Connectivity

• HDMI Input / Output : Supports up to 4K x 2K

Video Specifications

• Image Rejection (dB) : 80dB
• IF Rejection (dB) : 80dB
• Television Format : NTSC
• Video Frequency Response (Component Video) : 10Hz – 8MHz (–3dB)

Dimensions

• Depth (in) : 11-13/16
• Depth (mm) : 300
• Height (in) : 4-3/4
• Height (mm) : 121
• Weight (lb) : 10
• Width (in) : 17-5/16
• Width (mm) : 440
