Key Digital KDIP1022DEC 4K Enterprise AV Over IP Decoder
Brand New · Factory Sealed · Key Digital Authorized Dealer
$1,499.99
Free Canada-wide Shipping
•
Ships in 2 to 4 Days
end of _buybox_shipping
end of _buybox_core
end of _payments
end of _buybox_couponend of _xwarranty
- Available
- Free shipping
- 3yr Manufacturer Warranty
- 5% Price Promise
Trusted by 150,000+ Canadian customers since 2001
4K UHD AV over IP Decoder with Independent Video, Audio, KVM/USB Routing and Video Wall Processing. Audio De-Embed with Volume, Delay, and Bass/Mid/Treble Control, 2 port PoE LAN Switch, Local HDMI In, 3 port IR, RS-232, Trigger Master Controller / Control Gateway.
Features:
- Enterprise AV Over IP: Utilizes a managed gigabit network switch to enable video distribution, matrix switching, and extension
- Video Wall Processing: Encoder + Decoder systems create video walls with up to 16 vertical and 16 horizontal monitors
- Independent Switching: Video, Audio, and USB switching all independently routable routed for multi-layer systems
- Control: 3 multi-function ports may be used as third-party control interface, Compass Control ® Pro master controller, control extension via IP, or callable via KeyCode open API
- Key Digital ® App Ready: Network scan & detect populates pre-built GUI including image preview, and finger drag video wall layout control
- HDCP 2.2: Compliancy up to HDCP 2.2 and backward compliant
- 4K/Ultra HD Resolution: Support for 4096x2160 or 3840x2160 24/25/30Hz at 4:4:4/8 Bit or 60Hz at 4:2:0/8 Bit (10.2Gbps max bandwidth)
- 4K Down-scale: Incoming 4K resolution can be down-converted to 1080p or 720p at each decoder, enabling monitors to display content at optimal resolution at all times
- Audio De-Embedding: At Encoder and Decoder for ease of integration with audio systems
- Audio Pre-Amp: Variable level settings for volume, muting, EQ, balance, and lip-sync delay per Encoder and Decoder
- HDMI Pass-Through (ENC): Enables connection to local monitor or other AV Devices
- Local HDMI Input (DEC): Creates localized input option ideal for presentation spaces
- Signal Extension: Up to 330 ft. / 100 m @ 4K 24/25/30(4:4:4)/60(4:2:0) into network switch or point-to-point
- Power over Ethernet: Does not require power supply when integrated with compatible PoE network switch.
- Redundant Power Connection: Added reliability for non-PoE integration.
- Data Stream Bandwidth: < 900Mbps / Latency: <40ms at 4K. Less at lower resolution.
- Installation: Use KD-SMS16 to install up to twelve KD-IP822/ENC/DEC units in rack
- Dual LAN: Built-in switch enables network connectivity and PoE powering of connected devices.
- USB 2.0: Supports synchronous and isochronous connections (web cams not supported)
- HDMI ® and HDCP Licensing: Fully licensed and compatible with HDCP 2.2 and HDMI latest technology such as 4K/UHD 4:2:0/8bit at 60 f/s
- EDID Control: Internal library features 15 default EDID configurations and native EDID data from Output/Display devices connected to Decoder
- Hot Plug Detection Control: Enables integrator to choose if active signal voltage is forced to connected input devices
- Full Buffer System ™: Manages TMDS re-clocking / signal re-generation, HDCP authentication with source & display, EDID Control handshake, and Hot Plug control
- IR Sensor: Sensor powering via +5V IR In port collects line-of-sight IR from remote(s) without external IR connecting block
- Up/Down IR: Two channels of IR enable control to/from devices connected to Encoder and Decoder units
- RS-232: Bi-Directional control to/from Encoder and Decoder unit on Phoenix connector
- RS-232/TCP-IP Control Mode: Provides control of unit as well as connectivity status
- Lossless compressed digital audio: Support for Dolby ® TrueHD, Dolby ® Digital Plus, Dolby Atmos ®, and DTS-HD Master Audio ™
- Control System Support: Controllable by all IR, RS-232 & TCP/IP supported control systems
- via open API: Compass Control ® Pro, AMX ®, Control4 ®, Crestron ®, KNX ®, RTI ®, Savant, URC ®, Leviton ® etc.
- Compass Control ® Pro Inside: Built-in 3 port Compass Control ® Pro master controller.
- KD-ProCL1/2/4/8 Software Activation License. Required to activate iOS controllers.
Product Details
- Key Digital KDIP1022DEC
-
Brand New : Factory Sealed
- UPC : 815996021584
- EFLC : 12012
- Write a review
Warranty
Three Year Warranty
- Parts and Labour Warranty
- Canada-wide Coverage
- Key Digital Authorized
Returns
Easy Returns
- 30-day return window on eligible items
- Full refund issued in accordance with our return policy
