Klipsch DS-250W LCR Dual 5.25" In-Wall LCR Speaker

The Klipsch DS-250W LCR is a dual 5.25" in-wall speaker designed to deliver dynamic, detailed Klipsch sound for home theatre and 2-channel systems. Part of the Klipsch Designer Series, it combines dual polypropylene woofers with a 1" silk dome tweeter mated to a Tractrix horn.

Designed for clean architectural installations, the DS-250W LCR features Klipsch's patent-pending SkyHook tool-free installation system, which automatically engages the mounting dog legs with a preset clamping force. A bezel-free, paintable magnetic grille provides a discreet finished appearance.

Features:

• Dual 5.25" Woofers - Two 5.25" (13.34 cm) polypropylene woofers provide dynamic low- and mid-frequency performance.
• 1" Silk Dome Tweeter - Delivers detailed high-frequency reproduction.
• Tractrix Horn Technology - The tweeter is mated to a 90° x 90° Tractrix horn for controlled high-frequency dispersion.
• In-Wall LCR Design - Designed for use in home theatre systems or 2-channel installations.
• 92 dB Sensitivity - High sensitivity helps provide strong output with compatible amplification.
• SkyHook Tool-Free Installation - Automatically engages the mounting dog legs when the speaker is inserted into the wall cutout using a preset clamping force.
• Fast Installation - The SkyHook system is designed to reduce installation time by up to 75% while helping prevent overtightening.
• Infinite Baffle Enclosure - ABS construction is designed specifically for architectural in-wall installation.
• Bezel-Free Magnetic Grille - Redesigned magnetic steel grille provides clean integration into the surrounding space.
• Paintable Grille - White grille can be painted to better match the installation environment.
• Optional Install Kit - Compatible with the Klipsch IK-502-W II installation kit, sold separately.

Specifications:

Acoustic Performance:

• Speaker Type: Dual 5.25" In-Wall LCR Speaker
• Frequency Range: 73 Hz - 20 kHz +/- 3 dB
• Sensitivity: 92 dB @ 2.83V / 1m
• Coverage Angle: 100°
• Power Handling: 60W RMS / 240W Peak
• Impedance: 8 Ohm Compatible

Drivers:

• High-Frequency Driver: 1" (2.54 cm) Silk Dome Tweeter
• High-Frequency Horn: 90° x 90° Tractrix Horn
• Low-Frequency Drivers: Dual 5.25" (13.34 cm) Polypropylene Woofers

Construction & Installation:

• Enclosure Material: ABS
• Enclosure Type: Infinite Baffle
• Baffle / Frame: Black
• Grille: White Paintable Magnetic Grille
• Installation System: SkyHook Tool-Free Installation System
• Mounting Depth: 3.78" (9.35 cm)
• Cutout Dimensions: 16.5" H x 6.5" W (41.9 x 16.5 cm)
• Optional Install Kit: IK-502-W II (Sold Separately)

Dimensions & Weight:

• Width: 7.5" (19.1 cm)
• Height: 17.4" (44.2 cm)
• Depth: 3.8" (9.6 cm)
• Weight: 6.5 lb (2.95 kg)

What's in the Box:

• Flat Magnetic Grille
