TOA EM-600 Omnidirectional Flush-Mount Condenser Microphone

The TOA EM-600 is a compact omnidirectional condenser microphone designed for discreet, high-quality sound pickup in installed environments. With a slim 28 mm profile, it can be flush-mounted into ceilings, walls, or desks, making it ideal for conference rooms, boardrooms, classrooms, and commercial installations where visual impact must be minimal while maintaining clear and natural audio reproduction.

Features

• Ultra-compact flush-mount condenser microphone for installed applications
• Omnidirectional pickup pattern for consistent room coverage
• Electret condenser element for clear and accurate sound reproduction
• Flush-mount design suitable for ceilings, walls, or desks
• Balanced low-impedance output for professional audio systems

Specifications

Microphone

• Element: Electret condenser
• Polar pattern: Omnidirectional
• Impedance: 120 ohm, balanced
• Sensitivity: -36 dB at 1 kHz (0 dB = 1 V/Pa)
• Frequency response: 30 Hz to 20 kHz

Power and Connectivity

• Phantom power: 9 V to 52 V DC
• Output connector: XLR-3-12 equivalent

Environmental

• Operating temperature: 0 °C to +40 °C (32 °F to 104 °F)

Construction

• Body: Steel with white semi-gloss painted finish
• Head: Zinc-plated steel wire with white semi-gloss painted finish

Dimensions and Weight

• Dimensions: 28 mm diameter x 68 mm length (1.1 in x 2.68 in)
• Weight: 85 g (0.19 lb)

In the Box

• Rubber isolation rings x 2
• M20 mounting nut x 1
