Eliminates voltage irregularities & protects your AV system.

Improves Picture and Sound Quality

• The PM8-AV’s Power Cleaning and Filtration eliminate common symptoms of contaminated power (including loss of detail, pops, hisses, hums and visual artifacts) and allows your A/V equipment to perform up to its full capability.

Surge Protection

• Exclusive Protect or Disconnect™ circuitry. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to connected equipment.

Safety

• Engineered and built to meet the latest UL Safety requirements (UL 1449 3rd Edition)

Features:

Cable/Sat Protection

• Protects equipment from electrical surges that travel over cable, satellite, and antenna lines.

Telephone Line Protection

• Protects equipment from electrical surges that travel over telephone lines.

8 Outlets

• Eight (8) filtered and surge protected outlets.

Surge Protection

• Exclusive Protect or Disconnect™ circuitry. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to connected equipment.

Hi Def Ready

• Hi-Def Designed to work with your High Definition system.

Specifications:

General:

• Family: Floor Models
• Line Voltage: 120 (Volts)
• Number of Outlets: 8
• Outlet Descriptions: All 8 outlets filtered and surge protected
• Control: On/Off control to all outlets through power switch.
• Compliance: UL 1449 3rd Edition, 3000A
• AC Power Cord: 6 ft. captive cord
• Dimensions: 12" L x 5" W x 1.75" H (12.5" L Including brackets)
• Weight: 3.5 lbs

AC Protection:

• AC Protection Technology:
• Protect or Disconnect
• L-N, L-G, N-G Protection Modes
• Thermal Fusing
• Maximum Current Rating: 15 (Amps)
• Initial Clamping Level: 200V Peak

Filtration:

• Filtration Technology: RFI/EMI Filtration
• Filtration Rating: 45dB @ 100kHz - 1 MHz
