Audio-Technica AT-VM745xML Dual Moving Magnet Phono Cartridge

The Audio-Technica AT-VM745xML is a high-performance Dual Moving Magnet phono cartridge designed to deliver exceptional realism, precision, and musical detail from vinyl records. Part of the AT-VMx series, it closely mirrors the geometry of professional cutter heads used to create vinyl masters, ensuring accurate groove tracking, wide soundstage, and excellent channel separation.

This model features a lightweight nude Microlinear stylus capable of tracing record grooves with extreme accuracy, extracting subtle detail that elliptical and conical styli cannot resolve. A solid boron cantilever transmits vibrations significantly faster than aluminum, improving transient response and clarity, especially on dynamic musical passages. The die-cast aluminum body further enhances performance by minimizing resonance and unwanted coloration.

Features

• Premium Dual Moving Magnet phono cartridge
• Nude Microlinear stylus for extremely accurate groove tracing
• Solid boron cantilever for fast signal transmission and low distortion
• 90° V-shaped generator mirrors professional cutting head geometry
• Paratoroidal generator with stacked coils for improved efficiency
• Optimized PCUHD copper coils with reduced turns for enhanced transient response
• Two magnets aligned to left and right groove channels for superior separation
• Center shield plate reduces crosstalk and preserves stereo imaging
• Die-cast aluminum housing minimizes vibration and resonance
• Threaded mounting holes allow easy installation without nuts
• V-cut flip-up stylus protector aids accurate cueing
• Compatible with standard 1/2-inch mount turntable headshells
• Compatible with all stereo AT-VMx replacement styli

Specifications

Cartridge

• Type: Dual Moving Magnet
• Frequency response: 20 Hz – 27 kHz
• Output voltage: 3.7 mV (1 kHz, 5 cm/sec.)
• Channel separation: 26 dB (1 kHz)
• Output balance: 1.0 dB (1 kHz)
• Tracking force: 1.8 – 2.2 g (2.0 g standard)
• Vertical tracking angle: 20°

Electrical

• Coil impedance: 3.2 kΩ (1 kHz)
• DC resistance: 750 Ω
• Recommended load impedance: 47 kΩ
• Recommended load capacitance: 150 – 250 pF
• Coil inductance: 480 mH (1 kHz)

Stylus & Compliance

• Stylus type: Nude Microlinear
• Stylus curvature radius: 2.2 × 0.12 mil
• Static compliance: 20 × 10⁻⁶ cm/dyne
• Dynamic compliance: 7 × 10⁻⁶ cm/dyne (100 Hz)

Physical

• Dimensions: 29 × 18.3 × 17.5 mm
• Weight: 8.8 g
• Threaded mounting hole: M2.6 × 2
