Features:

• Multi-format Audio Multiplexing: DSP per output for independent matrix selection
• Analog to Analog Matrix with DSP
• Digital to Analog Matrix with DSP
• Digital to Digital Matrix
• Analog to Digital Matrix
• Audio Pre-Amp: Variable level settings for volume, muting, 3-band EQ, balance, and lip-sync delay per balanced output
• Audio Delay: Variable level set from 0ms to 170ms
• Audio Conversion: Analog to digital. Digital to analog
• Balanced or Unbalanced: Input audio type may be specified per input
• Lossless Compressed Digital Audio: Dolby® and DTS surround up to 5.1ch pass-thru
• Long Cable Runs: Enabled by balanced audio connection, signals may be run up to 1,000 ft.
• Control Integration: TCP/IP, RS-232, and USB with full bi-directional operation, front panel push buttons and LEDs, front/rear optical IR, serial IR
• Control System Support: Key Digital app ready. Key Digital Management Software Pro (KDMS Pro) ready, Compass Control Pro ready. Fully controllable by all IR, RS-232, and TCP/IP supported control systems via open API.
• Key Digital® App Ready: Scan & detect population for pre-built GUI and TCP/IP control via Key Digital® App

Specifications:

Technical:

• Input (each): Balanced/unbalanced line level audio on 6-pin terminal block. Accepts 2VRMS line audio input with a sampling rate of 48KHz
• Input (each): RCA female for digital audio following SPDIF format (IEC 60958). Supports sampling rate up to 192KHz
• Output (each): Balanced/unbalanced line level audio on 6-pin terminal block. Drives 2VRMS line audio input with a sampling rate of 48KHz
• Output (each): RCA female for digital audio following SPDIF format (IEC 60958). Supports sampling rate up to 192KHz
• K-Factor: 0.22% @ optimal EQ » Video Isolation (Crosstalk): -45dB @ 5MHz
• Analog Audio Max Input Level: 4dBu on 50kΩ, AC coupling
• Analog Audio Max Output Level: 4dBu on 150kΩ, DC coupling
• Audio Bandwidth: 20Hz to 20kHz @ 0dBu
• TND + Noise: 0.33% @0dBu @ 1kHz » PCM Max Input Level: 1Vpp on 75Ω, AC coupling
• PCM Max Output Level: 1Vpp on 75Ω, DC coupling
• Wired IR: modulated IR signal input, 0-5V TTL or -10 to +10V
• Power: 12V/2A (25W) AC Power Supply with Grounded, 2.1mm ID DC Power Jack with Screw In Type

General:

• Regulation: CE, RoHS, WEEE
• Rack Mount: 1U, 1 Rack Width (rack ears included)
• Enclosure: Black Metal
• Product Dimensions: 17.5" x 7" x 1.75"
• Product Weight: 6 lb

What's in the box:

• Power supply (qty 1) 12V/3A, 36W, desktop type, model KDSP40W12VC
• IR Remote control, model KD-REMOTEHM88
• 6-position terminal block (qty 17)
• Rack mount ears
