The Best of all Worlds

Fully Integrated HiFi TWS Solution

The FW5 integrates FiiO's various cutting edge technologies to bring a fully integrated high-fidelity true wireless solution. This is among the first TWS earphones to integrate a high-end Bluetooth chip, high-performance DAC and a meticulously designed audio circuit to achieve a big quality jump in all aspects. Let the FWS show you what new high-fidelity TWS earphones are truly capable of.

Heartily Robust

Independent AK4332

Let there be high fidelity in a true wireless earphone! The FW5 contains an efficient AKM VELVET SOUND DAC-the AK4332 which features high-performance decoding abilities. This chip is capable of signal-to- noise ratio up to 106dB, distortion as low as -96dB, and dynamic range up to 102dB. The above parameters were measured values of the FW5's intermal circuit

More Throughput

Qualcomm QCC5141 Bluetooth chip

For true wireless earphones, the Bluetooth chip is undoubtedly one of the most important parts. The FW5 employs the high-end Qualcomm QCC5141 that supports Bluetooth 5.2 for stable and high-performance Bluetooth audio thanks to the chip's dual DSP and dual-core architecture. Additionally, the FW5 is Snapdragon Sound certified as a testament to its highly capable audio abilities.

Acoustic Goodness

One ear at a time

The FW5 has been developed by the same FiO R&D team that created the high-fidelity wired FH9 lagship. In the tiny space of a true wireless earphone, the team managed to ft a large 10mm dynamic driver that handles the low and mid-range frequencies, while higher frequencies are reproduced by 2 Knowies BA drivers. These drivers work together to give powertul yet textured bass while reproducing every last detail in the treble.

More Than Just Big

10mm large dynamic

The FW5 features a large 10mm dynamic driver for the low and mid frequencies. The driver has been designed specifically to maximize the sound quality from its N50 neodymium magnets. These N50 magnets, with their high magnetic density, allow for better dynamics and make the sound stage more grand for a thoroughly bold sound.

Bringing Out the Big Guns

DLC diaphragm with PU

The FW5 uses PU as the material of choice for the gasket surrounding the diaphragm of the dynamic driver, Since its flexbility anDLC diaphragm with PU d high damping coefficient allow for lusher vocals and faster transient response. The diaphragm of the dynamic driver is made of DLC, which features favorable properties such as high rigidity and light weight which allow for less unwanted breakup over the dynamic driver. This leads to reduced non-linear distorion and ultimately better resolution

For every last detail

Knowles high- frequency BA drivers

For high frequencies, Knowles BA drivers are used for each channel. These BA drivers are placed in the sound tube near the ear to reduce high-frequency loss as sound waves travel to the listener's ear. This design ensures that even tones like those at 16kHz still come through clearly. This design allows the FW5 to feature an airy, exceptionally detailed treble that captures every nuance of your music.

HiFi TWS is the New Thing

High-Res LHDC/aptX Adaptive Bluetooth format support

The FW5 reaffirms FiiO's commitment to being at the forefront of new audio technologies, with not only Snapdragon Sound certification but also support for LHDC/aptX Adaptive for the ultimate quality in true wireless audio. This support ensures both a massive upgrade in the sending and receiving of high-quality wireless audio and a major improvement in compatibility with various devices.

Carefully-tuned sound

Pleasing frequency response curve

As the fist TWS earphones fully developed by FiO, for the W5 we did not put our focus on features such as active noise canceling (ANC) Instead, we focused on binging the ultimate in sound quality in a fuly integrated TWS earphone. And while R is easy b adjust the frequency response curve via DSP, we chose not to do so. We instead chose to refine the physical design of the unit to reduce distortion, retain the unique sound of the drivers-to maimize the sound quality through good design to fully respect the original music.

Easy to Use with 0 Accidental Touches

4 physical buttons

Based on user feedback from the UTWs Bluetooth series, the development team chose to employ 2 physical buttons per ear unit for operation. The 2 physical buttons make it easier to control play and pause of the curret track compared to the traditional 1-button setup. In addition, the 2 buttons are placed perpendicularly to the wearing angle making them easier to press without resorting to too much force.

Fun without Worries!

IPX4 water resistance

The FW5 features IPX4 water resistance thanks to cleverty placed fims and meshes. A 0.02mm water resistant film is placed in the gap between the buttons and the shell to not only prevent water from getting in but to also ensure good feel when pressing the buttons. A custom water-resistant and sound-pemeable mesh covers the sound nozzle an microphone openings to both prevent water from getting in but also letting sound through at the same time. With the FW5, you can go about life's joys without worying about damaging your great-sounding pair of earphones.

A Reassuring Partner

21+ hours battery life

Despite packing a high-performance DAC chip, high-end Bluetooth chip, and a carefully designed audio circuit, the FW5 features battery long enough to easily meet daily usage needs. With its large built-in 65mAh battery, the FW5 can be used for up to 7 hours on a single charge. The 380mAh charging case allows for total battery life of more than 21 hours.

Box Switch

Power switch linked to the case

When opening the FW5 charging case, the ear units are automatically turned on and paired with the last device. When the ear units are placed back into the charging case, the FW5 ear units automatically turn off to save power.

Simply clear

LED indicator lights

Both the charging case and the FW5 ear units each feature LED indicator lights to let you quickly know their status. The 4 indicator lights on the charging case not only indicate the battery remaining and the charging status, but also indicate if the ear units are in the case. The ear units each also contain a white indicator light that clearly indicates paifing and connection status.

Enjoy communicating

Dual-mic cVc noise

Each ear unit of the FW5 features 2 microphones that work together with cVc noise cancellation technology for clearer voice calls to make communicating a joy.

Muliple favors in one place

2 sets of ear tips included

The FW5 comes standard with a set of balanced ear tips as well as 2 alternate sets of vocal ear tips for different sound preferences. The vocal ear tips are made with medical-grade Silicone featuring a soft texture that makes it comfortable to wear-making them a perfect combination of sound quality and superior comfort.

Specifications:

• Name/Model:FW5
• Weight:
  • ≈ 6.4 g x 2 (units)
  • ≈44.4 g (charging box only)
  • ≈57.2 g (in total)
• Bluetooth: Bluetooth 5.2
• Bluetooth(5.2) codec: SBC/AAC/aptx/aptx Adaptive/LHDC
• Bluetooth distance: ≈10 metres
• Firmware upgrade: OTA via FiiO Control
• FiiO Control: Yes
• Main buttons:
  • Click: Pause/Play/Answer incoming call
  • Double tap: voice assistant (left unit) / turn ambient mode off or on (right unit)
  • Long press for 1s: reject the call/hang up the call
  • Press and hold for 2s: power on
  • Press and hold for 5s: power off
• Dimensions:
• 28.4*22.9*22.6mm (units)
• 68.4*43.9*32.3 mm (charging box)
• Hardware solution: DAC: AK4332 Bluetooth: QCC5141
• Config: 1DD 2BAs
• Max sampling rate: 96kHz-24bit
• Supported protocol: A2DP/AVRCP/HFP/HSP
• Secondary button:
• Click: volume-(left unit)/volume+(right unit)/answer call
• Long press for 1s: previous song (left unit)/next song (right unit)/reject call/hang up call
• Long press 8s: reset

Supported Features (Setup via FiiO Control)

• Game mode: Bluetooth latency will be lower, power consumption will be increased.
• Charging protection: Units will stop charging when reach to 85%
• Channel balance: L12 ~ R12 (0.5 dB per level)
• Battery life:
  • ≈7h (units) + 14h (charging box)
  • ≈7h (units) + 14h (charging box)
• Power input: 5V 1A and above
• Impedance: 32Ω@1kHz
• Frequency response: 20Hz-20kHz
• Indicator switch: Set the earphones indicator on and off
• Power saving shutdown: Set the timed shutdown time of earphones
• Filters: Four filters available
• Battery capacity:
• Units: 65mAh
• Charging box: 380mAh
• Call time:
• ≈5h30min
• Test conditions: aptX, call: volume 24, units: volume 18
• Sensitivity: 108dB@1mW
• SNR (DAC+AMP): ≥106dB
