Truly Balanced Decoding and Amplification

The K7 has a six-stage audio circuit with truly balanced analog and digital sections - which helps to reduce crosstalk and reproduce music to a great extent, allowing you to better enjoy the purity of your music.

Democratized High-Quality Balanced Amplification

Couldn't sound better

Using the same THX AAA 788+ amplifiers as the K9 Pro, the K7 is capable of outputting 560mW into a 300Ω load at 1% distortion, and 2000mW into a 32Ω load at 1% distortion. This ensures both low and high impedance headphones are powered with aplomb, and most importantly lets you experience musicality that's sure to tug at your heartstrings.

Dual AK4493SEQ

Rich and delicate overall sound

The left and right channels are each equipped with an efficient high-performance AK4493SEQ. With this DAC's pleasant timbre, its rich and delicate overall sound will let you rediscover your music all over again.

Robust Decoding Capabilities

Take a trip around the music world

The XMOS XUF208 decoder chip uses dual clock management to handle various music formats with ease, allowing you to easily listen to many audio formats.

RGB Indicator Lights

For a colorful entrance

The RGB indicator lights are capable of displaying single colors as well as mixed colors, with a unique light flow effect during power-on/off or input switching. Dazzling and vivid light effects give your desk some much needed spice.

HD Bluetooth a Reassuring Wireless Experience

The Bluetooth version of the K7 is available. It uses the QCC5124 Bluetooth chip*, supporting high-definition Bluetooth formats like LDAC/aptX HD/aptX Adaptive. When using the K7 BT, switch the input mode to Bluetooth, and you will acquire low-latency Bluetooth transmission and hi-res sound quality. Also, the app control* helps to further enhance your wireless experience.

* Bluetooth 5.1, supports LDAC/aptX Adaptive/aptX/aptX HD/aptX LL/AAC/SBC.

* Through the FiiO Control app, the K7 BT can achieve the following functions: upgrade Bluetooth firmware, select Bluetooth codec, customize PEQ, etc.

Multiple Intelligent Protection Systems

Worry-free listening

Overheating, overload, DC protection systems ensure that the K7 always operates at its best, so you can always enjoy a wonderful listening experience in multiple scenarios.

Consistent Inside and Out

For pure clean listening

The K7 features a power design consisting of multiple independent stages, with a voltage of each stage being regulated by low-noise LDOs. Feeding this power design is an external 12V switching power supply. All in all, the K7's power design is designed to supply plentiful, clean power for an extraordinary listening experience.

Numerous Exciting Possibilities All Within Reach

Variety of inputs and outputs all in one place

The K7 contains USB, optical, coaxial, and RCA inputs. Outputs are 6.35mm single-ended and 4.4mm balanced for pleasant listening no matter the headphones.

Input Switching

With just one click

One key controls switching between the 4 different inputs, with a flowing light effect to indicate when the input has switched and is ready.

3 Different Outputs

With just one touch

One touch of a handy key allows you to switch between 3 output modes (for use with headphones, with speakers, or use as a DAC).

Two Gain Levels

Find a comfortable volume

The high and low hardware gain levels allow you to easily adjust the K7 to handle headphones of various impedances and sensitivities for a rich and consistent listening experience.

Quality Construction

For an elegant air

The K7 features an all-aluminum alloy construction, carefully finished with CNC and other processes. Its elegant black color is perfectly complemented by the gold accents of THX and Hi-Res Audio badges topped with a splash of color from the RGB lights for a thoroughly luxurious appearance.

Precisely Tuned Volume

For truly moving experience

Thanks to ADC curve reconstruction, experience a smooth 112 steps of adjustable volume free of channel imbalances and noise - ensuring that every note is faithfully reproduced.

Lightweight All-in-one

Simple and elegant

The K7 features a petite design that only measures 55mm thick and with a footprint of less than 1/3 of an A4-sized sheet of paper - allowing it to fit perfectly on modern desks.

A Jack of All Trades

Capable under any scenario

Specifications:

General specifications:

• Name/Model No.: K7 BT
• Color:Black
• Weight:=610g
• Size:  12 x 16.8 x 5.5 centimeters
• Maximum supported sampling rate:
  • PCM 384kHz-32bit/DSD256(USB DAC)
  • PCM 192kHz-24bit(COAX)
  • PCM 96KHz-24bit(OPT)
• Recommended headphone impedance: 16~300Ω
• Hardware solution:
  • DAC: AK4493S*2 , USB: XMOS XUF208
  • Voume IC:NJU72315 * 2
  • AMP:THX AAA 788+ * 2
• Volume Scroll: Potentiometer+ADC Sampling
• FiiO Control: K7 BT supported
• Firmware upgrade: XMOS can be upgraded via USB
• Sampling rate indication:
  • Blue:44.1KHz/48KHz
  • Yellow:88.2/96/176.4/192/352.8/384KHz
  • Green:DSD64/128/256

Buttons and interfaces:

• Buttons: input button*1+gain switch*1+output switch*1
• LINE IN: RCA sockets
• OPT IN: TOSLINK
• BAL PO: Standard 4.4mm port
• USB: USB B(data)
• LINE OUT: RCA sockets
• COAX IN: RCA sockets
• SE PO: Standard 6.35 mm port

Power parameters:

• Power supply: DC 12V/2A

Audio parameters:

• Line output performance parameters:
  • Frequency response:
    • 20Hz~20KHz:±<0.4dB(UAC)
    • 20Hz~20kHz:±<0.8dB(SPDIF IN)
    • 20Hz~50KHz:±<2.2dB(UAC)
    • 20Hz~50kHz:±<1.7dB(SPDIF IN)
  • THD+N: <0.0005%(1kHz/10kΩ/dbA)
  • Crosstalk: ≥ 102dB (1kHz/10kΩ)
  • Noise floor: <3uV(dbA)
  • SNR: ≥ 116dB (dbA, UAC)
  • Output level: ≥ 2Vrms
• Headphone output performance parameters(6.35mm):
  • Output power1: L+R≥ 1220mW+1220mW(32Ω /THD+N<1%)
  • Output power2: L+R≥ 140mW+140mW(300Ω / THD+N<1%)
  • Frequency response:
    • 20Hz~20KHz:±<0.3dB(UAC)
    • 20Hz~20kHz:±<0.7dB(SPDIF IN )
    • 20Hz~50KHz:±<2.1dB(UAC)
    • 20Hz~50kHz:±<1.6dB(SPDIF IN )
  • THD+N: <0.0003% (1 kHz/32Ω/dbA)
  • Output impedance: <1Ω(32Ω)
  • Crosstalk: ≥ 77dB (1 kHz/32Ω)
  • Noise floor:
    • <3.1uV(dbA, AUX IN)
    • <4.4uV(dbA, UAC)
  • SNR:
    • ≥ 128dB (dbA, AUX IN)
    • ≥ 120dB (dbA, UAC)
  • Peak output voltage: ≥ 18.9Vpp
• Balanced headphone output performance parameters(4.4mm):
  • Output power2: L+R≥ 2000mW+2000mW(32Ω /THD+N<1%)
  • Output power3: L+R≥ 560mW+560mW(300Ω / THD+N<1%)
  • Frequency response:
    • 20Hz~20KHz:±<0.3dB(UAC)
    • 20Hz~20kHz:±<0.7dB(SPDIF IN )
    • 20Hz~50KHz:±<2.1dB(UAC)
    • 20Hz~50kHz:±<1.6dB(SPDIF IN )
  • THD+N: <0.0003% (1 kHz/32Ω/dbA)
  • Output impedance: <1Ω(32Ω)
  • Crosstalk: ≥ 124dB(1 kHz/32Ω)
  • Noise floor:
    • <5.1uV(dbA, AUX IN)
    • <7.7uV(dbA, UAC)
  • SNR:
    • ≥ 128dB (dbA, AUX IN)
    • ≥ 120dB (dbA, UAC)
  • Peak output voltage: ≥ 37.7Vpp
