The WS-5325M includes a wireless transmitter WM-5325, a lavalier microphone YP-M5310, and a diversity wireless tuner WT-5810. The WM-5325 wireless transmitter has been manufactured for use with a UHF system. Thanks to the PLL-synthesizer system, 64 different operating frequencies are made available. A high output power ensures stable radio signal transmission. The YP-M5310 employs an electret condenser microphone element and has been designed for use in speech reinforcement applications. The WT-5810 is a PLL-synthesizer controlled double superhetrodyne diversity tuner designed to be used with a UHF wireless system. It employs a compander noise reduction circuit to minimize the influence of ambient RF noise.
Specifications:
- Product Composition: Wireless transmitter WM-5325 x 1, Lavalier microphone YP-M5310 x 1, Diversity wireless tuner WT-5810 x 1
- Frequency Range: 576 - 865 MHz (*1), UHF
- Tone Frequency: 32.768 kHz
- Operating Temperature: -10 ° Cto +50 ° C(14 °F to 122 °F)
- Accessory: AC adapter (*2) x 1, Screw driver x 1, Strage case x 1, Neck strap x 1
Wireless Transmitter
- Modulation: Frequency modulation
- Channel Selectable: 64 channels (the number of channels may differ from country to country)
- RF Carrier Power: Less than 50 mW (Factory preset 10 mW ERP)
- Oscillator: PLL synthesized
- Maximum Input Level: -14 dB to -29 dB (*3) (Audio level control: Min. to Max.)
- Battery: WB-2000 (WB-2000-2 contains 2 pieces) rechargeable battery (option) or AA alkaline dry cell battery
- Battery Life: Approx. 13 h (when the WB-2000 rechargeable battery is used), Approx. 10 h (when the alkaline battery is used)
- Indicator: Power/Battery lamps
- Antenna: Built-in type
- Dimensions: 62 (W) x 102.5 (H) x 23 (D) mm (2.44 x 4.04" x 0.91")
- Weight: 90 g (0.2 lb) (with battery)
Lavalier Microphone
- Microphone Element: Electret condenser type: Omnidirectional
- Sensitivity: -64 dB ±3 dB (0 dB = 1 V/0.1 Pa, 1 kHz)
- Cord Length: 1.3 m (4.27 ft)
- Weight: 20 g (0.71 oz) (cable included)
Diversity Wireless Tuner
Product Details
- TOA WS-5325M H01US
-
Brand New : Factory Sealed
