Klipsch Cornwall IV 15" 3-Way Horn-Loaded Floorstanding Speaker (Each)

The Klipsch Cornwall IV is a three-way Heritage Series horn-loaded loudspeaker designed for exceptional efficiency, dynamics and powerful full-range performance. Built in Hope, Arkansas, the Cornwall IV combines a large 15" woofer with horn-loaded midrange and high-frequency compression drivers in a substantial cabinet designed to deliver the scale and impact of live music.

The fourth-generation Cornwall incorporates the K-702 midrange compression driver with a 1.75" polyimide diaphragm, coupled to a modified Tractrix horn featuring Klipsch Mumps technology for more consistent midrange coverage throughout the listening area. A K-107-TI titanium-diaphragm compression driver handles high frequencies, while the K-33-E 15" fiber-composite woofer and Tractrix ports provide powerful, clean low-frequency reproduction.

Features:

• 3-Way Horn-Loaded Design - Combines horn-loaded high-frequency and midrange compression drivers with a large 15" woofer.
• K-702 Midrange Compression Driver - Features a 1.75" (4.45 cm) polyimide diaphragm for exceptional detail and dynamics.
• Modified Tractrix Midrange Horn - Incorporates patented Klipsch Mumps technology for more even polar response and consistent sound throughout the listening area.
• Titanium High-Frequency Driver - K-107-TI 1" (2.54 cm) titanium-diaphragm compression driver delivers detailed high-frequency reproduction.
• 15" Fiber-Composite Woofer - K-33-E woofer provides powerful low-frequency performance.
• Tractrix Ports - Custom-designed inner flares help reduce air turbulence and port noise for cleaner, more powerful bass.
• 102 dB Sensitivity - Exceptionally high efficiency allows substantial output from relatively modest amplifier power.
• High-Fidelity Network - Completely revoiced network uses premium components and draws from the classic three-way steep-slope designs of the Klipschorn and La Scala.
• Bi-Wire / Bi-Amp Capability - Premium aluminum input panel and dual binding posts support standard wiring, bi-wiring and bi-amping.
• Book-Matched Wood Veneer - Heritage Series veneer leaves are precisely arranged to create a mirror image at the splice joint.
• Matched Pairs - Heritage loudspeaker pairs are grain-matched using veneer panels from the same timber and receive sequential serial numbers.
• Heritage Construction - Cabinets are assembled using high-grade adhesives and fasteners with an emphasis on long-term durability.
• Made in Hope, Arkansas - Designed and made in the USA using domestic and imported components.

Specifications:

Acoustic Performance:

• Speaker Type: 3-Way 15" Horn-Loaded Loudspeaker
• Frequency Response (+/- 4 dB): 34 Hz - 20 kHz
• Sensitivity: 102 dB @ 2.83V / 1m
• Power Handling: 100W Continuous / 400W Peak
• Maximum SPL: 119 dB Continuous
• Nominal Impedance: 8 Ohms Compatible
• High-Frequency Crossover: 5,000 Hz
• Mid-Frequency Crossover: 700 Hz

Drivers:

• High-Frequency Driver: K-107-TI 1" (2.54 cm) Titanium Diaphragm Compression Driver
• Midrange Driver: K-702 1.75" (4.45 cm) Polyimide Diaphragm Compression Driver
• Midrange Horn: Modified Tractrix Horn with Klipsch Mumps Technology
• Low-Frequency Driver: K-33-E 15" (38.1 cm) Fiber-Composite Cone Woofer
• Bass Loading: Tractrix Ports

Construction & Connections:

• Enclosure Material: MDF with Fine Veneers
• Inputs: Dual Binding Posts
• Bi-Wire: Yes
• Bi-Amp: Yes

Dimensions & Weight:

• Height: 38" (96.52 cm)
• Width: 25.3" (64.3 cm)
• Depth: 15.5" (39.4 cm)
• Weight: 95.76 lb (43.43 kg)
