WiiM Bar 3.0.2 Dolby Atmos Smart Soundbar

The WiiM Bar is a display-first smart soundbar combining immersive 3.0.2-channel Dolby Atmos and DTS:X playback with WiiM's extensive music streaming platform. Its eight-driver acoustic system, four passive radiators and top-firing height channels deliver cinematic sound from a single soundbar, while a front-facing 2.1" full-colour touchscreen provides direct access to playback, sources, EQ, presets, album art and more.

Designed as the foundation of an expandable home theatre, the WiiM Bar can grow into a wireless 5.1.2 system using compatible WiiM surround speakers and subwoofer devices sold separately. HDMI eARC, Wi-Fi 6E, Ethernet, Bluetooth 5.4, optical, line-in and USB provide flexible connectivity for television, movies, gaming and music.

Features:

• 3.0.2-Channel Spatial Audio - Native 3.0.2 configuration with dedicated top-firing height channels for immersive Dolby Atmos and DTS:X playback.
• Expandable to 5.1.2 - Add compatible WiiM wireless surround and subwoofer devices to build a complete 5.1.2 home theatre system.
• 8-Driver Acoustic System - Three front mid-woofers, three front tweeters and two top-firing full-range height drivers provide dedicated reproduction across the soundstage.
• Four Passive Radiators - Two front and two rear passive radiators reinforce low-frequency performance without requiring a separate subwoofer.
• 135W System Power - Integrated amplification provides up to 135 watts of total system power.
• 2.1" Full-Colour Touch Display - Glass-covered round Hi-Res LCD touchscreen displays album art, track information, time, EQ, Smart Presets, Recently Played content, clock faces and dynamic wallpapers.
• On-Device Touch Control - Control playback, skip tracks, like content, select sources and quickly access EQ directly from the display.
• RoomFit Auto-Correction - WiiM RoomFit analyzes the listening environment using a compatible phone's microphones and optimizes playback for the room and speaker placement.
• Clear Voice & AI Dialog Enhancement - Helps bring speech forward for improved dialogue intelligibility during movies and television.
• Multiple Sound Modes - Movie, Music, Voice Enhance and Night modes tailor playback for different listening situations.
• Advanced EQ - Includes 24 preset EQ settings, 10-band Graphic EQ and supported 10-band Parametric EQ adjustment through the WiiM Home App.
• HDMI eARC - Provides a direct home theatre audio connection to compatible televisions.
• Dolby Atmos & DTS:X - Supports LPCM, Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, AC3, DTS and DTS:X.
• Wi-Fi 6E - Tri-band 2.4 GHz, 5 GHz and 6 GHz wireless networking provides high-performance network connectivity.
• Bluetooth 5.4 - Supports Bluetooth input and output with compatible devices.
• Extensive Music Streaming - Supports more than 20 music services through the WiiM Home App along with Google Cast Audio, Spotify Connect, TIDAL Connect, Qobuz Connect, Amazon Music Cast, DLNA/UPnP, Qplay 3.0, LMS and Roon.
• WiiM Multi-Room Audio - Group the soundbar with compatible WiiM devices for synchronized whole-home listening.
• USB Media Library - Connect compatible USB storage and browse a personal media library through the WiiM Home App.
• USB Media Server - Can serve media from connected USB storage to other compatible WiiM and DLNA devices on the same network.
• Voice Control - Supports Alexa and Google Assistant control, with hands-free operation available through compatible external voice-assistant devices.
• Included WiiM Bar Remote - Rechargeable remote provides playback, volume, source, sound mode, mute, standby and supported voice controls.
• Console or Wall Placement - Place the WiiM Bar on a TV console or install it using the included wall-mount brackets.

Specifications:

General:

• Product: WiiM Bar
• Model: BAR001
• Product Type: Display-First Smart Soundbar
• Native Channel Configuration: 3.0.2
• Expandable Configuration: Up to 5.1.2 with Compatible WiiM Devices
• Maximum System Power: 135W

Speaker System:

• Acoustic System: 8 Active Drivers with 4 Passive Radiators
• Front Mid-Woofers: 3 x 110 x 52 mm (4.33" x 2.05")
• Front Tweeters: 3 x 52 x 52 mm (2.05" x 2.05")
• Height Drivers: 2 x 52 x 52 mm (2.05" x 2.05") Full-Range, Top-Firing
• Passive Radiators: 4 x 115 x 50 mm (4.53" x 1.97")
• Passive Radiator Placement: 2 Front / 2 Rear

Audio Formats & Home Theatre:

• Supported Formats: LPCM, Dolby Atmos / TrueHD / DD+, AC3, DTS, DTS:X
• Dolby Atmos: Yes
• DTS:X: Yes
• TV Connection: HDMI eARC
• Wireless Surround Expansion: Yes, with Compatible WiiM Devices
• Wireless Subwoofer Expansion: Yes, with Compatible WiiM Devices

Sound Processing & EQ:

• Room Correction: RoomFit Auto-Correction
• Dialogue: Clear Voice and AI Dialog Enhancement
• Sound Modes: Movie, Music, Voice Enhance, Night
• Preset EQ: 24 Presets
• Graphic EQ: 10-Band
• Parametric EQ: 10-Band, Where Supported in WiiM Home App
• Per-Source EQ: Supported Where Available

Display & Controls:

• Display: 2.1" Hi-Res Full-Colour Round LCD Touchscreen
• Display Cover: Glass
• Display Functions: Album Art, Track Information, Time, EQ, Smart Presets, Recently Played, Clock Faces, Dynamic Wallpapers and Album Art Standby
• Capacitive Controls: Volume Up, Volume Down, Play/Pause, Source
• Status Indicator: RGB+W LED
• App: WiiM Home App
• Voice Control: Alexa and Google Assistant
• Remote: WiiM Bar Remote

Wired Connectivity:

• HDMI: HDMI eARC
• Digital Audio: Optical Input
• Analog Audio: Line Input
• Ethernet: 10/100 Mbps
• USB: USB Host for Storage
• USB Audio: Input or Output

Wireless Connectivity:

• Wi-Fi: Wi-Fi 6E
• Wi-Fi Bands: 2.4 GHz / 5 GHz / 6 GHz
• Wi-Fi Standard: 802.11 b/g/n/ax
• Bluetooth: Bluetooth 5.4
• Bluetooth Profiles: BLE, A2DP Rx/Tx, AVRCP, HID
• LE Audio: Supported via Software Update
• Bluetooth Input: Yes
• Bluetooth Output: Yes, Where Supported
• AirPlay 2: Not Supported

Streaming:

• Streaming Services: 20+ Services Through the WiiM Home App
• Streaming Protocols: Google Cast Audio / Chromecast Audio, Spotify Connect, TIDAL Connect, Qobuz Connect, Amazon Music Cast, DLNA/UPnP, Qplay 3.0, LMS, Roon
• Example Services: Spotify, Amazon Music, YouTube Music, TIDAL, Qobuz, Deezer, TuneIn, SoundCloud, Pandora, iHeartRadio, vTuner, SoundMachine, KKBOX, Soundtrack Your Brand
• WiiM Multi-Room: Yes
• Alexa Multi-Room: Supported Where Available
• Google Cast Multi-Room: Supported Where Available

USB Media:

• USB Host: Yes
• Media Library: Supported Through WiiM Home App
• Media Server: Yes, for Compatible WiiM and DLNA Devices
• Supported File Systems: FAT32, NTFS, EXT4 Where Supported

Dimensions & Weight:

• Width: 41.7" (1060 mm / 106 cm)
• Depth: 4.1" (105 mm / 10.5 cm)
• Height: 3.1" (80 mm / 8 cm)
• Weight: 11.02 lb (5 kg)
• Placement: TV Console or Wall Mount

Power:

• Power Input: 100-240V AC
• Frequency: 50/60 Hz
• Maximum System Power: 135W

What's in the Box:

• WiiM Bar
• WiiM Bar Remote
• User Guide
• Power Cable
• HDMI Cable
• Optical Cable
• 2 x Wall Brackets with Screws
