Audio-Technica AT-VM745xML Dual Moving Magnet Phono Cartridge
The Audio-Technica AT-VM745xML is a high-performance Dual Moving Magnet phono cartridge designed to deliver exceptional realism, precision, and musical detail from vinyl records. Part of the AT-VMx series, it closely mirrors the geometry of professional cutter heads used to create vinyl masters, ensuring accurate groove tracking, wide soundstage, and excellent channel separation.
This model features a lightweight nude Microlinear stylus capable of tracing record grooves with extreme accuracy, extracting subtle detail that elliptical and conical styli cannot resolve. A solid boron cantilever transmits vibrations significantly faster than aluminum, improving transient response and clarity, especially on dynamic musical passages. The die-cast aluminum body further enhances performance by minimizing resonance and unwanted coloration.
Features
- Premium Dual Moving Magnet phono cartridge
- Nude Microlinear stylus for extremely accurate groove tracing
- Solid boron cantilever for fast signal transmission and low distortion
- 90° V-shaped generator mirrors professional cutting head geometry
- Paratoroidal generator with stacked coils for improved efficiency
- Optimized PCUHD copper coils with reduced turns for enhanced transient response
- Two magnets aligned to left and right groove channels for superior separation
- Center shield plate reduces crosstalk and preserves stereo imaging
- Die-cast aluminum housing minimizes vibration and resonance
- Threaded mounting holes allow easy installation without nuts
- V-cut flip-up stylus protector aids accurate cueing
- Compatible with standard 1/2-inch mount turntable headshells
- Compatible with all stereo AT-VMx replacement styli
Specifications
Cartridge
- Type: Dual Moving Magnet
- Frequency response: 20 Hz – 27 kHz
- Output voltage: 3.7 mV (1 kHz, 5 cm/sec.)
- Channel separation: 26 dB (1 kHz)
- Output balance: 1.0 dB (1 kHz)
- Tracking force: 1.8 – 2.2 g (2.0 g standard)
- Vertical tracking angle: 20°
Electrical
- Coil impedance: 3.2 kΩ (1 kHz)
- DC resistance: 750 Ω
- Recommended load impedance: 47 kΩ
- Recommended load capacitance: 150 – 250 pF
- Coil inductance: 480 mH (1 kHz)
Stylus & Compliance
- Stylus type: Nude Microlinear
- Stylus curvature radius: 2.2 × 0.12 mil
- Static compliance: 20 × 10⁻⁶ cm/dyne
- Dynamic compliance: 7 × 10⁻⁶ cm/dyne (100 Hz)
Physical
- Dimensions: 29 × 18.3 × 17.5 mm
- Weight: 8.8 g
- Threaded mounting hole: M2.6 × 2
Product Details
- Audio-Technica AT-VM745xML
-
Brand New : Factory Sealed
- EAN : 4961310163235
- EFLC : 15419
