Make your home theater dreams a daily reality.

The TX-NR828 has built-in WiFi for app controlled network audio streaming, and built-in Bluetooth serves hi-res, lossless, and compressed audio files (including 192 kHz/24-bit FLAC, DSD, and Dolby® TrueHD) to your home theater from mobile devices, and it's all about stunning sound. Behind the brushed aluminum faceplate all seven channels have Three-Stage Inverted Darlington Circuitry, which effortlessly handles big dynamic gains without distorting, as THX Select2 Plus™ certification proves, and renders all audio in extraordinary detail.

Eight 4K-ready HDMI® inputs, and a frontside MHL™ (for mobile devices), decode dazzling audio and video. 7.2 multichannel pre-outs, powered Zone 2 outputs, and bi-amping capability make this a very flexible AVR. Audio is masterfully processed, and 4K video source signals are cleanly passed-through, and standard video can be upscaled to 4K. Two HDMI outputs (one with Audio Return Channel) are included to connect your TV or even a projector for an authentic big-screen experience.

Owning an Onkyo A/V receiver is not just about having big sound on movie night. It's about maximizing the sound of enjoyment in your daily life..

---

Hear Precisely What the Director Intended

Perfecting your home theater experience, THX certification guarantees theater-reference volumes in medium-sized rooms with minimal distortion.

The TX-NR828 meets the most demanding & rigorous performance certification: it has to pass 75 test categories, 2,000 tests, covering 14,000 data points.

Built-In Wireless & Bluetooth

Send a huge range of hi-res, lossless, and compressed audio files (including 192 kHz/24-bit FLAC, DSD, and Dolby® TrueHD) to your home theater from smartphone, PC, tablet, NAS devices, and online sources using the Onkyo remote app to control playback.

The TX-NR828 connects to your home network wirelessly- withoutcables or adapters.

Also, you can pair up to ten compatible Bluetooth devices and stream high quality wireless audio using built-in Bluetooth 2.1. The enhanced data rate provides better data transfer.

---

The Foundation of Onkyo Sound

At the core of Onkyo's Signature sound is Onkyo's proprietary Wide Range Amplifier Technology (WRAT). This technology includes discrete low-negative-feedback amplifiers for punchy, true-to-life sound; closed ground-loop circuits to reduce noise, and high instantaneous current to counter impedance fluctuations.

From the quietest dialog passages to booming action scenes, Onkyo's exclusive amp technology enhances the audio of your movies, music and games like you've never before experienced.

Working in concert with WRAT amps, Three-Stage Inverted Darlington Circuitry is also a core Onkyo technology. It incorporates a low negative feedback design that conducts more sublimely natural sound. It's used on all channels to handle reference-level playback without distortion.

Take a look at the TX-NR828's WRAT features here.

Powerful Bass AND Clear Vocals

Phase-Matching Bass optimizes low frequencies and preserves mid-range clarity. This means that powerful bass plays back with clear vocals; it doesn't overpower them.

Onkyo's PM Bass boost technology improves the phase timing to preserve the natural clarity of the mid-range, and allows vocals and strings to shine while maintaining a smooth, powerful bass response at all volume levels.

8 HDMI Inputs (1 Front/7 Rear) and 2 Outputs

Qdeo™ technology from Marvell upscales standard video to silky-smooth 1080p (for regular HDTVs) and to an incredible 4K on compatible displays. Also, this receiver will passthrough 4K resolution from compatible source devices.

The TX-NR828's eight HDMI inputs take surround sound formats from Dolby® TrueHD and DTS-HD Master Audio™ and supports 3D video. .

The two HDMI outputs: one supports Audio Return Channel, so you can boost your TV's sound through your receiver, and another for a second TV or projector.

Music from Everywhere Sounds Even Better Through an Onkyo

The TX-NR828 has the most internet radio and music streaming services of any receiver in its class. Period!

And it connects to your home network wirelessly- no cable or adapter required.

These services are easily selectable using the receiver's GUI or the Onkyo remote control app. Explore more than 10,000 radio stations and enjoy their albums and playlists with theater-fidelity sound.

---

Quick & Easy Remote Control App

The Onkyo remote control app for iPod touch®/iPhone,® Android, and Kindle devices is a convenient way to control your home entertainment from anywhere within wireless range. The app has a clear graphical interface to control playback, adjust settings and handle content across multiple zones.

The app serves hi-res, lossless, and compressed audio files (including 192 kHz/24-bit FLAC, DSD, and Dolby® TrueHD) to the TX-NR828 from your mobile devices, and gives it stunning sound.

MHL™ & InstaPrevue for Easy Video Switching

MHL displays your mobile's 1080p video and other media on your HDTV with 7.1 channels of surround sound.

InstaPrevue™ technology names your HDMI sources and then displays live video thumbnails of available content. Switch sources easily, with just a glance. No need to remember what's connected to which port.

---

Audyssey Technology for Superior Sound

Audyssey MultEQ® room-correction technology delivers clear, well-balanced, natural sound.

Audyssey Dynamic EQ® maintains consistent bass, tonal and surround sound effects at different volume levels.

Audyssey Dynamic Volume® automatically compensates for volume fluctuations, for example during loud commercial breaks.

More Speaker Set-Up Options for Greater Dimension

Dolby Pro Logic IIz gives you Front Height channels with 7.1-channel upmixing from stereo sources.

Audyssey DSX lets you augment your speaker setup by adding two additional Front Wide channels, expanding the width of the soundstage, or two Front Height speakers to add a vertical dimension to movies and games.

---

Overlaid Menus for Quick Adjustments

The Quick Set-Up button on your remote puts menus over the program you're watching to switch inputs or change a settings without interrupting your viewing.

Similarly, the Home Menu button calls up simple icons for choosing a media source and menus for system settings.

Multi-Room Playback

The TX-NR828 features Powered Zone 2 outputs and Zone 2/3 line-outs. This lets you assign two channels to power audio in a room equipped with speakers. An existing hi-fi system in a third room can also be connected via the line-out, enabling the use of the A/V receiver as a pre-amp and audio server.

Control content in all three zones via remote app; play the same song in all zones using Whole House Mode; or enjoy a different song in each room.

Amplifier Section
Power Output
All Channels	160 W (6 Ohms, 1 kHz, 0.7%, 2 channels driven)
Front L/R	160 W (6 Ohms, 1 kHz, 0.7%, 2 channels driven)
Center	160 W (6 Ohms, 1 kHz, 0.7%, 2 channels driven)
Surround L/R	160 W (6 Ohms, 1 kHz, 0.7%, 2 channels driven)
Surround Back L/R	160 W (6 Ohms, 1 kHz, 0.7%, 2 channels driven)
Dynamic Power	300 W (3 Ohms, Front) 250 W (4 ohms, 1 Front) 150 W (8 ohms, Front)
THD+N (Total Harmonic Distortion + Noise)	0.08% (20 Hz-20 kHz, Rated Power)
Damping Factor	60 (Front, 1 kHz, 8 Ohms)
Input Sensitivity and Impedance	200 mV/470 Ohms (Line) 2.5 mV/47 k-ohms (Phono MM)
Rated RCA Output Level and Impedance	200 mV/470 Ohms (Line Out)
Maximum RCA Output Level and Impedance	4.6 V/470 Ohms (Line Out)
Phono Overload	70 mV (MM, 1 kHz, 0.5%)
Frequency Response	5 Hz-100 kHz/+1 dB, -3 dB (Direct Mode)
Tone Control	±10 dB, 30 Hz (Bass) ±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio	106 dB (Line, IHF-A) 80 dB (Phono MM, IHF-A)
Speaker Impedance	4 Ohms–16 Ohms or 6 Ohms-16 Ohms
Video Section
Input Sensitivity/Output Level and Impedance
Video	1 Vp-p/75 Ohms (Component) 0.7 Vp-p/75 Ohms (Component PB/CB, PR/CR) 1 Vp-p/75 Ohms (Composite)
Component Video Frequency Response	5 Hz–100 MHz, -3dB
Tuner Section
Tuning Frequency Range
FM	87.5 MHz–107.9 MHz
AM	530 kHz–1,710 kHz
FM/AM Preset Memory	40 stations
General
Power Supply	AC 120 V, 60 Hz
Power Consumption	8.1 A
No-Sound Power Consumption	85 W
Standby Power Consumption	0.1 W
Dimensions (W x H x D)	17 1/8" x 7 13/16" x 15 11/16" (435 x 198.5 x 398 mm)
Weight	33.1 lbs (15.0 kg)

One-Year Manufacturer's Warranty

This item is features a one-year parts and labor warranty.
