An Easy Entry Point into the World of Fully Immersive Home Theater
Continuing our mission to bring quality to every level of home entertainment, Onkyo presents the TX-SR309—an entry-level A/V receiver fine-tuned to power your system right out of the box. Set-up is simple and adjustments are easy, thanks to a new overlaid on-screen display. Also new at this level is PLL jitter-cleaning circuit technology to reduce distortion, and a front-panel USB port that provides a high-quality digital link to your iPod®/iPhone®. To get the best from your compressed audio files, the TX-SR309 employs Onkyo’s proprietary Advanced Music Optimizer. Naturally, the receiver also handles high-def, lossless audio in the form of Dolby® TrueHD and DTS-HD Master Audio™. These are carried by three HDMI® inputs that also support immersive 3D video content. And whether you’re gaming in 3D or not, you can choose from four customized audio modes to match your gaming content. It all adds up to one high-value proposition.
Special Feature
- Three 1080p capable HDMI inputs (V1.4a)
- 4 DSP Gaming Modes: Rock, Sports, Action, and Role Playing
- New On-sceen display via HDMI
- Burr-Brown DACs for improved jitter and clearer sound
Amplifier | |
| # Channels | 5.1 |
| Power (8ohms 20-20kHz 0.08%) /Ch | 65W |
| Power (8ohms 20-20kHz 0.05%) /Ch | - |
| THX Certified | - |
| Continuous 6ohms Rated | YES |
| Certified 4ohms performance | - |
| All Discrete Circuitry | - |
| 3-Stage Inverted Darlington Circuitry | - |
| Dual PUSH-PULL Design | - |
| Independent Block Construction (Amp/Preprocessor) | - |
| Toroidal Transformer | - |
| Independent Power Supply | - |
| Bi-amp Capability For Front | - |
| BTL Capability For Front | - |
Processing | |
| DOLBY Decoder | True HD, DD Plus |
| DTS Decoder | DTS-HD Master Audio |
| Dolby PLIIz | - |
| ONKYO GAME Surround Modes | YES |
| DTS Surround Sensation Speaker / Headphone | - / - |
| Neural Surround | - |
| THX Processing Mode | - |
| Audyssey Dynamic EQ | - |
| Audyssey Dynamic Volume | - |
| Direct/Pure Mode | YES / - |
| Music Optimizer | YES |
| 192K/24 Bit DACs | YES (Burr-Brown) |
| VLSC | - |
| isf Certified Calibration Control | - |
Connectivity | |
| Audio I/O | 5 / 1 |
| Phono Input | - |
| Digital Audio IN (OPT/COAX) | 2 / 1 |
| Digital Audio OUT (OPT/COAX) | - |
| Composite I/O | 4 / 1 |
| S-Video I/O | - |
| Component Video I/O | 2 / 1 |
| Front-Panel A/V | - |
| Front-Panel Optical | - |
| Front-Panel Portable input (stereo mini jack) | YES |
| HDMI I/O | 3 / 1 |
| HDMI Version | V1.4a (supporting 3D video and Audio Return Channel) |
| Component Video Upconversion | - |
| Analog To HDMI UpConversion | - |
| 1080i Upscaling | - |
| 1080p Upscaling | - |
| Multi-Channel Input | - |
| Analog Pre-Outs | Sub |
| Speaker A/+B | YES |
| Powered Zone2 | - |
| Zone 2 Line Out | - |
| Zone 2 Video Out | - |
| Zone 3 Line Out | - |
| U-Port | YES |
| iPod Ready | YES (optional UP-A1) |
| HD Radio Ready | YES (optional UP-HT1) |
| XM Radio Ready | - |
| SIRIUS Radio Ready | - |
| Internet Radio Capable | - |
| Streaming Audio From PC | - |
| Streaming Audio From USB memory | - |
Integration Access | |
| RS-232 | - |
| IR Input | - |
| Ethernet | - |
| ONKYO-RI System Control | YES |
| 12V Trigger | - |
Miscellaneous | |
| Pre-Pro/Learning Remote | - / - |
| Back-Lit Remote | - |
| On Screen Remote Programming | - |
| Bi-directional Remote Setup via GUI | - |
| Activity Based Remote | - |
| Color-Coded Speaker Terminals | YES |
| Auto Speaker Calibration W/Mic. | - |
| OSD Out | YES (basic overlay) |
| Solid Aluminum Front | - |
| Warranty | 2 YEARS |
Amplifier Section | |
| Power Output* (8 ohm, 20 Hz-20 kHz, FTC) | - |
| Front L/R | 65 W/Ch |
| Center | 65 W |
| Surround L/R | 65 W/Ch |
| Surround Back | - |
| Power Output* (6 ohm, 1 kHz, FTC) | - |
| Front L/R | 90 W/Ch |
| Center | 90 W |
| Surround L/R | 90 W/Ch |
| Surround Back | - |
| Dynamic Power** (front) | - |
| 3 ohm | 160 |
| 4 ohm | 125 |
| 8 ohm | 85 |
| THD (Rated Power) | 0.7 % (2 channels driven) |
| Damping Factor (1 kHz, 8 ohm) | 60 |
| Input Sensitivity and Impedance | - |
| PHONO MM | - |
| CD and TAPE Play | 200 mV, 47 k ohm |
| Output Level and Impedance | - |
| TAPE REC | 200 mV, 470 ohm |
| PRE OUT | 1.0 V, 470 ohm |
| Frequency Response | 20 Hz-50 kHz |
| S/N Ratio | - |
| PHONO (MM) | - |
| CD/TAPE | 100 dB (IHF-A, 0.5 V input) |
| Phono Overload (1 kHz) | - |
| Tone Controls | - |
| BASS | +/- 10 dB at 50 Hz |
| TREBLE | +/- 10 dB at 20 kHz |
Tuner Section | |
| Usable Sensitivity | - |
| FM Mono | 11.2 dBf, 1.0 uV (75 ohm IHF) |
| FM Stereo | 17.2 dBf, 2.0 uV (75 ohm IHF) |
| AM | 30 uV |
| S/N Ratio | - |
| FM Mono | 76 dB (IHF-A) |
| FM Stereo | 70 dB (IHF-A) |
| AM | 40 dB |
| THD | - |
| FM Mono | 0.2 % |
| FM Stereo | 0.3 % |
| AM | 0.7 % |
| FM Stereo Separation | 45 dB at 1 kHz,30 dB at 100 Hz-10 kHz |
General | |
| Dimensions (W x H x D) | 17 1/8" x 5 15/16" x 12 15/16" |
| Weight | 17.6 lbs |
Two-Year Parts and Labor by Onkyo Canada
