Features:

• HDMI Switching: 2/4 HDMI sources to 1 HDMI output/display
• Ultra HD/4K Support: 4096x2160 or 3840x2160 24/25/30/60hz at 4:4:4 (signals up to 18Gbps bandwidth)
• HDCP Licensing: Fully licensed and compatible with HDCP 2.2
• HDR10 and Dolby Vision®: More life-like images through a greater range of luminance levels
• Resolution Support: Supports all SD, HD, and VESA (VGA, SVGA, XGA, WXGA, SXGA, UXGA) up to 4096x2160p
• Deep Color Support: Up to UHD/4K 30Hz 4:4:4/12 bits or 60Hz 4:4:4/8 bit
• Audio De-embedding: Audio of the selected HDMI input is output at the digital Optical and analog 3.5mm stereo connectors
• Auto-Sensing: Automatic selection of newly detected source and switching from newly disconnected source via hot plug detection voltage when enabled
• Full Buffer System ™: Manages TMDS re-clocking / signal re-generation, HDCP authentication to source & display, and EDID Control handshake
• EDID Management: Internal library with 15 internal EDID handshakes including 4K with HDR in addition to native EDID data copied from the output/display
• Lossless Compressed Digital Audio: Dolby® TrueHD, Dolby® Digital Plus, DTS-HD Master Audio ™, and Dolby® Atmos
• CEC Pass-thru: From connected display to selected HDMI source
• Control: Front panel buttons/LEDs, Optical IR
• Control System Support: Compass Control® Pro ready. Fully controllable by all IR supported control systems

Specifications:

Technical:

• Input (Each): HDMI Connector, Type A, 19 Pin Female
• Output: HDMI Connector, Type A, 19 Pin Female
• Bandwidth: TMDS bandwidth 18 Gb/s
• DDC Signal (Data): Input DDC Signal - 5 Volts p-p (TTL)
• HDMI Video/Audio Signal: Input Video Signal - 1.2 Volts p-p
• Power Supply: KD-PS5V1ASC, 5V/1A, 100-240VAC, 50-60Hz, Interchangeable head, screw-in connector

General:

• Regulation: CE, RoHS, WEEE
• Enclosure: Black Metal
• Product Dimensions: KD-S2x1X - 4.3" x 1.1" x 2.8"
• Product Weight: KD-S2x1X - 0.5 lb

What's in the box:

• Power Supply (qty 1) 5V/1A, 5W, wall type, model KDSP5V1ASC
• Mounting Brackets: 2 L-shaped
• IR Remote: KDRMSWPROK
