Exclusive Protect or Disconnect™ Circuitry

Safeguards equipment against all surges. In the event of a catastrophic surge such as lightning, it completely disconnects AC power to connected equipment.

Signal Perfect™ Circuitry

Optimized phone line surge protection circuitry ensures a clean, clear signal. It features solid-state SIDACtor® and autor-resetting PTCR's for maximum protection and reliability.

Features:

• EMI/RFI Filtration Circuitry for Clean, Unimpeded Power.
• Protect-or-Disconnect™ Circuitry
• In/Out Telco/LAN Connectors.
• Removable, paintable cover ensures seamless fit with any décor.
• Two Diagnostic Lights (LED) Power On/Protection OK and Line Fault.
• Thin Profile - Only 1.5 inches deep.
• Convenient display feature; turn cover around to hide diagnostic lights.

Specifications:

General:

• Family: Direct Plug Ins
• Line Voltage: 120 (Volts)
• Number of Outlets: 2
• Outlet Descriptions: Both outlets filtered and surge protected
• Compliance: C-UL (UL standard #1449)
• Dimensions: 3.25" W X 1.625" D X 5.25" H
• Weight: 0.65 lbs

AC Protection:

• AC Protection Technology:
• Protect or Disconnect
• L-N, L-G, N-G Protection Modes
• Thermal Fusing
• Maximum Current Rating: 15 (Amps)
• Initial Clamping Level: 200V Peak

Filtration:

• Filtration Technology: RFI/EMI Filtration
• Filtration Rating: 50 dB @ 100 kHz - 1 MHz
• Signal Line Protection: 1 LAN/Tel
