Onkyo TXRZ30 + SVS Prime Complete Home Theater Speaker System Bundle BLACK ASH

Build an immersive multichannel home theater around the 9.2-channel Onkyo TXRZ30 AV receiver and a coordinated collection of SVS Prime loudspeakers. The system combines the receiver with SVS Prime Bookshelf, Prime Center, Prime Satellite and Prime Elevation speakers for front, dialogue, surround and height-channel duties.

The Onkyo TXRZ30 provides nine amplified channels, Dolby Atmos, DTS:X, IMAX Enhanced and Dirac Live Room Correction Full Bandwidth. Its 9.2-channel processing and six HDMI inputs provide the control and processing foundation for the included SVS speaker system.

The SVS Prime speakers share related driver, crossover and cabinet technologies designed for coherent multichannel reproduction. Prime Bookshelf speakers provide a compact full-range foundation, the true three-way Prime Center focuses on clear dialogue, Prime Satellites handle flexible surround duties, and two pairs of Prime Elevation speakers provide versatile placement for height effects or other home-theater channels.

This bundle includes a mix of regular and open-box products as specifically identified below. The Prime Center and Prime Satellite Pair are open-box products.

Bundle Includes

• 1 × Onkyo TXRZ30 9.2-Channel AV Receiver
• 1 × SVS Prime Center Center Channel Loudspeaker BLACK ASH - Open Box
• 1 × SVS Prime Satellite Speaker BLACK ASH (Pair) - Open Box
• 2 × SVS Prime Elevation Satellite Speaker (Pair) BLACK ASH
• 1 × SVS 'Prime Bookshelf' Bookshelf Loudspeaker BLACK ASH (Pair)

Features

• Onkyo TXRZ30 with 9.2-channel processing and nine amplified channels.
• Dirac Live Room Correction Full Bandwidth license included with the TXRZ30.
• Dolby Atmos, Dolby Surround, DTS:X, Neural:X and IMAX Enhanced support.
• Six HDMI inputs and two HDMI outputs with eARC, plus 8K/4K Ultra HD support.
• SVS Prime Center true three-way design with vertically aligned tweeter and midrange plus dual 5.25-inch woofers.
• SVS Prime Satellite speakers use a 1-inch aluminum dome tweeter and 4.5-inch woofer in a compact rear-ported cabinet.
• SVS Prime Elevation speakers provide direct-radiating full-range height effects capability and flexible home-theater placement.
• SVS Prime Bookshelf speakers combine a 1-inch aluminum dome tweeter with a 6.5-inch woofer and SoundMatch crossover network.
• SVS Prime speakers use FEA-optimized cabinet and driver design elements with premium crossover components.

Onkyo TXRZ30 Specifications

• Channels: 9 amplified channels; 9.2-channel processing.
• Amplification: Class AB.
• Rated output: 9 × 170 W at 6 ohms, 1 kHz, 1% THD, one channel driven, IEC.
• Frequency response: 5 Hz-100 kHz (+1/-3 dB).
• HDMI: 6 inputs / 2 outputs with eARC.
• Video support: 8K/4K Ultra HD, Dolby Vision, HDR10+, HDCP 2.3, HDMI 2.1a VRR, QFT, ALLM and SBTM.
• Analog video: 1 component and 2 composite inputs.
• Analog audio: 6 RCA inputs and 1 RCA phono input.
• Digital audio: 1 optical and 1 coaxial input.
• Preamp outputs: 9.2-channel RCA with 2 independent subwoofer outputs.
• Zone 2: Stereo RCA.
• Surround formats: Dolby Atmos, Dolby Surround, DTS:X, Neural:X and IMAX Enhanced.
• Streaming/connectivity: Wi-Fi, Bluetooth, Chromecast built-in, AirPlay 2, Spotify, Amazon Music HD, Tidal, Deezer and TuneIn; Roon Tested.
• Room correction: Dirac Live Room Correction Full Bandwidth, 20 Hz-20 kHz; optional Dirac Live Bass Control.
• Dimensions (W × H × D): 17.1 × 7 × 15.1 in (435 × 177.5 × 382.5 mm).
• Product weight: 25.4 lb (11.5 kg).

SVS Prime Center Specifications - Open Box

• Design: True three-way center-channel loudspeaker.
• Tweeter: 1-inch aluminum dome with FEA-optimized diffuser.
• Midrange: 3.5-inch polypropylene-cone driver in a dedicated sealed enclosure.
• Woofers: Dual 5.25-inch polypropylene-cone woofers.
• Crossover: 3-way SoundMatch network; woofer-to-midrange 350 Hz and midrange-to-tweeter 2.4 kHz, both with 12 dB/octave slopes.
• Rated bandwidth: 48 Hz-25 kHz (+/-3 dB).
• Nominal impedance: 8 ohms.
• Sensitivity: 86 dB (2.83 V @ 1 m, full-space, 300 Hz-3 kHz).
• Recommended amplifier power: 20-200 W.
• Cabinet dimensions (H × W × D): 7.6 × 18.6 × 8.3 in (193 × 472 × 211 mm).
• Overall dimensions (H × W × D): 7.7 × 18.6 × 9.2 in (196 × 472 × 234 mm).
• Unboxed weight: 20.2 lb (9.2 kg).

SVS Prime Satellite Pair Specifications - Open Box

• Design: Two-way satellite loudspeakers.
• Tweeter: 1-inch aluminum dome with FEA-optimized diffuser.
• Woofer: 4.5-inch polypropylene-cone woofer.
• Crossover: SoundMatch 2-way network; tweeter-to-woofer crossover at 2.3 kHz with 12 dB/octave slopes.
• Rated bandwidth: 69 Hz-25 kHz (+/-3 dB).
• Nominal impedance: 8 ohms.
• Sensitivity: 85 dB (2.83 V @ 1 m, full-space, 300 Hz-3 kHz).
• Recommended amplifier power: 20-150 W.
• Cabinet dimensions per speaker (H × W × D): 8.75 × 4.9 × 6 in (222 × 124 × 152 mm).
• Overall dimensions per speaker (H × W × D): 8.85 × 4.9 × 6.3 in (225 × 124 × 160 mm).
• Unboxed weight per speaker: 6.5 lb (2.9 kg).

SVS Prime Elevation Specifications - 2 Pairs

• Design: Versatile direct-radiating height-effects and home-theater speaker.
• Tweeter: 1-inch aluminum dome.
• Woofer: 4.5-inch.
• Frequency response: 55 Hz-25 kHz (+/-3 dB).
• Port: 1-inch.
• Dimensions per speaker (H × W × D): 9.25 × 5.4 × 7.9 in (235 × 137 × 201 mm).
• Weight per speaker: 7.8 lb (3.5 kg).

SVS Prime Bookshelf Pair Specifications

• Design: Two-way bookshelf loudspeakers.
• Tweeter: 1-inch aluminum dome with FEA-optimized diffuser.
• Woofer: 6.5-inch polypropylene-cone woofer.
• Crossover: SoundMatch 2-way network; tweeter-to-woofer crossover at 2.3 kHz with 12 dB/octave slopes.
• Rated bandwidth: 48 Hz-25 kHz (+/-3 dB).
• Nominal impedance: 8 ohms.
• Sensitivity: 87 dB (2.83 V @ 1 m, full-space, 300 Hz-3 kHz).
• Recommended amplifier power: 20-150 W.
• Cabinet dimensions per speaker (H × W × D): 13.2 × 8 × 9.4 in (335 × 203 × 239 mm).
• Overall dimensions per speaker (H × W × D): 13.3 × 8 × 10.3 in (338 × 203 × 262 mm).
• Unboxed weight per speaker: 15.5 lb (7.0 kg).

What's in the Box

• 1 × Onkyo TXRZ30 9.2-Channel AV Receiver
• 1 × SVS Prime Center Center Channel Loudspeaker BLACK ASH - Open Box
• 1 × SVS Prime Satellite Speaker BLACK ASH (Pair) - Open Box
• 2 × SVS Prime Elevation Satellite Speaker (Pair) BLACK ASH
• 1 × SVS 'Prime Bookshelf' Bookshelf Loudspeaker BLACK ASH (Pair)
