EverSolo DMP-A6 Master Gen 2 & AMP-F2 with Triangle Borea BR04 Stereo System Bundle BLACK

This high-fidelity stereo bundle combines the EverSolo DMP-A6 Master Edition Gen 2 all-in-one music streamer, the EverSolo AMP-F2 Class D power amplifier, and a pair of Triangle Borea BR04 bookshelf loudspeakers.

The DMP-A6 Master Edition Gen 2 handles high-resolution streaming, DAC conversion, music-library management and volume-controlled analog output through balanced XLR or unbalanced RCA connections. Its fully balanced architecture, dual ES9038Q2M DACs and XMOS XU316 audio interface provide a capable source and preamplifier front end for the system.

The AMP-F2 provides 145W RMS per channel into 8 ohms and 250W RMS per channel into 4 ohms, while the Triangle Borea BR04 speakers combine a 25mm EFS silk-dome tweeter with a 16cm natural cellulose midwoofer in a front-ported two-way design. Together, the components create a compact but powerful stereo system suited to dedicated music listening in rooms from 10 to 40 m².

Bundle Includes

• 1 x EverSolo DMP-A6 Master Gen 2 All-In-One Streamer [] BLACK - Model A6 Master Gen 2
• 1 x Eversolo AMP-F2 Class D Power Amplifier - Model AMP-F2
• 1 x Triangle Borea BR04 Two Way Bookshelf Loudspeaker 6.5 Inch Midwoofer EFS Tweeter (Pair) BLACK ASH - Model BR04 Black Ash

Features

• EverSolo DMP-A6 Master Edition Gen 2 combines high-resolution music streaming, DAC decoding, music-library management and analog pre-output capability.
• Dual ES9038Q2M DAC chips independently process the left and right channels.
• XMOS XU316 audio interface supports up to DSD512 Native and PCM 768kHz/32-bit decoding.
• Fully balanced circuit architecture provides XLR balanced and RCA unbalanced analog outputs.
• Supports streaming and music services including TIDAL, Qobuz, HIGHRESAUDIO, Amazon Music, Apple Music, Roon Ready and TIDAL Connect.
• Built-in M.2 NVMe SSD slot supports storage expansion up to 4TB.
• HDMI ARC allows direct TV audio input to the DMP-A6 Master Edition Gen 2.
• AMP-F2 uses an efficient Class D amplification architecture with the Starke Sound NS600 amplifier module.
• AMP-F2 delivers 145W RMS per channel into 8 ohms and 250W RMS per channel into 4 ohms.
• Bridgeable AMP-F2 design supports flexible stereo or mono-channel configurations.
• Balanced XLR and unbalanced RCA inputs provide flexible connection options.
• 12V trigger input and output allow synchronized power control with compatible components.
• Triangle Borea BR04 uses a two-way front-ported bass-reflex design.
• 25mm EFS silk-dome tweeter with waveguide provides precise high-frequency dispersion.
• 16cm natural cellulose pulp midwoofer delivers warm, realistic vocals and controlled bass.
• Double binding posts support bi-wiring and bi-amplification.
• DVAS system reduces parasitic vibrations for improved clarity and dynamics.
• BR04 is recommended for rooms from 10 to 40 m².

EverSolo DMP-A6 Master Gen 2 Specifications

• Model: EVERSOLO DMP-A6 Master Edition Gen 2
• Display: 6-inch LCD Touchscreen
• Internal Memory: 4GB DDR4 + 32GB eMMC
• DAC: Dual ES9038Q2M
• Audio Processor: XMOS XU316
• Op-Amp Chip: OPA1612
• Power Supply: Low-noise linear power supply
• Built-in SSD Slot: M.2 NVMe 3.0 2280, supports up to 4TB
• USB-A Ports: 2 x USB 3.0
• Ethernet: RJ-45 10/100/1000Mbps
• Wireless Network: Wi-Fi 2.4GHz + 5GHz dual-band
• Music Playback and DAC Decoding: Up to Stereo DSD512, PCM 768kHz 32-bit and MQA
• Streaming: Roon Ready, DLNA, TIDAL Connect
• Bluetooth Audio Input: Bluetooth 5.0 with SBC/AAC
• USB-B Audio Input: Windows 10/11, Mac, Android and iOS compatibility
• Optical/Coaxial Audio Input: Up to Stereo PCM 192kHz 24-bit, DoP64 and MQA
• HDMI ARC Input: Up to Stereo PCM 192kHz/24-bit
• USB Audio Output: Up to Stereo DSD512 Native, PCM 768kHz 32-bit and MQA
• HDMI Audio Output: DSD64 Native multichannel / PCM 192kHz multichannel raw output, up to 5.1
• Optical/Coaxial Audio Output: Up to Stereo PCM 192kHz 24-bit, DoP64 and MQA
• Analog Audio Output: XLR balanced + RCA unbalanced pre-output
• XLR Output Level: 5.2V
• XLR Frequency Response: 20Hz-20kHz (±0.15dB)
• XLR Dynamic Range: >128dB
• XLR SNR: >128dB A-weighted
• XLR THD+N: <0.000087% (-121dB)
• RCA Output Level: 2.6V
• RCA Frequency Response: 20Hz-20kHz (±0.2dB)
• RCA Dynamic Range: >125dB
• RCA SNR: >125dB A-weighted
• RCA THD+N: <0.0001% (-120dB)
• Power Supply Requirement: AC 110-240V, 50/60Hz
• Rated Power: 13W
• Dimensions: 7.36" x 10.63" x 3.54" (187 x 270 x 90 mm)

Eversolo AMP-F2 Specifications

• Amplifier Type: Class D
• Channels: 2
• Output Power at 8 Ohms: 145W RMS per channel at 1% THD
• Output Power at 4 Ohms: 250W RMS per channel at 1% THD
• Bridged Output at 4 Ohms: 280W RMS at 1% THD
• Bridged Output at 2 Ohms: 450W RMS at 1% THD
• XLR Input Impedance: 22k Ohms
• RCA Input Impedance: 11k Ohms
• Input Sensitivity: 2.7V
• Gain: 21.5dB
• Frequency Response: 10Hz-20kHz -1dB
• Maximum Output Current Per Channel: 16.5A / 33A bridged
• Output Terminals: 2 pairs beryllium copper binding posts
• True Balanced Circuit: Yes
• Signal-to-Noise Ratio: >110dB A-weighted at 4 Ohms / 250W
• THD: 0.003% at 10W / 1kHz
• Inputs: 2-channel RCA and 2-channel XLR
• Standby Power Consumption: ≤0.5W
• Idle Power Consumption: ≤14W
• Maximum Power Consumption: 900W
• Control: 12V trigger input and output
• Dimensions: 10.63" x 8.98" x 3.15" (270 x 228 x 80 mm)
• Weight: 8.05 lb (3.65 kg)

Triangle Borea BR04 Specifications

• Type: Bass Reflex Bookshelf, front port
• Crossover: 2-way
• Sensitivity: 90dB
• Frequency Response: 44Hz-22kHz (+/-3dB)
• Nominal Impedance: 8 Ohms
• Minimum Impedance: 4.6 Ohms
• Recommended Amplifier Power: 25-130W RMS at 8 Ohms
• Power Handling: 110W
• Tweeter: 25mm (1") silk dome with EFS Technology
• Midwoofer: 16cm (6.5") natural cellulose pulp membrane
• Crossover Frequency: 3200Hz
• Speaker Dimensions (W x H x D): 8.66" x 16.73" x 12.36" (220 x 425 x 314 mm)
• Unit Weight: 18.96 lb (8.6 kg)
• Package Dimensions Pair (L x H x D): 20.67" x 18.90" x 14.76" (525 x 480 x 375 mm)
• Packaged Weight Pair: 41.89 lb (19 kg)

What's in the Box

• 1 x EverSolo DMP-A6 Master Gen 2 All-In-One Streamer BLACK
• 1 x Eversolo AMP-F2 Class D Power Amplifier
• 2 x Triangle Borea BR04 Bookshelf Speakers (Pair)
• 2 x Magnetic Protection Grilles
• 8 x Rubber Feet
