A combination of the newest technologies and exclusive Yamaha features. Technologies include HDMI with 4K Pass-Through and upscaling and AirPlay support. Multipoint YPAO Reflected Sound Control (R.S.C.), Dialogue Lift and Dialogue Level Adjustment and ECO mode demonstrate Yamaha’s innovation.

• 7-channel powerful surround sound (95W per channel)
• Aluminum front panel for enhanced rigidity
• Discrete amp configuration and Pure Direct
• Network functions such as AirPlay and AV Controller app
• 4K Pass-Through and upscaling for next-generation high resolution images
• High quality video processing with precise deinterlacing
• HDMI (6 in [1on front])/2 out) with 3D and Audio Return Channel
• YPAO Reflected Sound Control (R.S.C.) sound optimization with multi-point measurement
• Dialogue Lift and Dialogue Level Adjustment for natural dialogue and vocals
• Newly designed preset remote unit
•  HDMI Zone B for audio/video streaming to another room (same content as main room)
• Versatile Zone control such as Zone 2 on/off and control on front panel
• Advanced multi-language GUI on-screen display with album art (English, German, French, Spanish, Russian and Chinese)
• HDMI front panel input for devices such as camcorders and digital cameras
• ECO mode operation for about 20% less power consumption




Amplifier Section	Channel	7.2
	Rated Output Power (1kHz, 2ch driven)	110W (8ohms, 0.9% THD)
	Rated Output Power (20Hz-20kHz, 2ch driven)	95W (8ohms, 0.09% THD)
	Dynamic Power per Channel (8/6/4/2 ohms)	140/180/210/250W
Surround Sound Processing	CINEMA DSP	Yes (3D)
	DSP Programs	17
	Compressed Music Enhancer	Yes
	Virtual Presence Speaker	Yes
	Dialogue Lift	Yes (no presence speakers required)
	SILENT CINEMA / Virtual CINEMA DSP	Yes
	Dolby TrueHD	Yes
	Dolby Digital Plus	Yes
	Dolby Pro Logic IIx	Yes
	DTS-HD Master Audio	Yes
	Dialog Level Adjustment	Yes
Audio Features	Pure Direct	Yes (with video on mode)
	YPAO multi-point measurement	Yes (R.S.C)
	Adaptive DRC (Dynamic Range Control)	Yes
	Initial Volume & Maximum Volume Setting	Yes
	Bi-amp capability	Yes
	Audio Delay	Yes (0-500 ms)
	192kHz/24-bit DACs for all channels	Yes (Burr-Brown)
Video Features	HDMI 3D passthrough	Yes
	HDMI Audio Return Channel	Yes
	HDMI upscaling	Yes (Analog to HDMI / HDMI to HDMI)
	Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync	Yes
	4K Pass-through & 4K Upscaling	Yes
Connectivity	HDMI Input/Output	6 (front 1) / 2 (Simultaneous)
	HDMI CEC	Yes (SCENE, Device Control)
	USB Input	iPod/iPhone/iPad, USB Memory, Portable Audio Player
	Network Port	Yes
	Front AV Input	HDMI/USB/Composite
	Digital Audio Input/Output: Optical	2 / 0
	Digital Audio Input/Output: Coaxial	2 / 0
	Analog Audio Input/Output	4 / 1
	Component Video Input/Output	2 / 1
	Composite Video Input/Output	5 (front 1) / 1
	Preout	7.2ch
	Headphone Output	1
	AirPlay	Yes
Tuner Section	FM/AM Tuner	Yes
User Interface	On-screen display	Graphical User Interface
	SCENE	SCENE (4 sets)
	App Control	Yes (iPhone/iPad/Android phone/tablet)
	Web Browser Control	Yes
	Remote Control Unit	Yes (Preset)
Zone Control	Zone 2 Audio Output	Line output
	Powered Zone	Zone 2
	+12V Trigger Output	1
	Remote (IR) Input/Output	1 / 1
	Party Mode	Yes
General	Standby Power Consumption (IR only)	≤0.1W
	Auto Power Down	Yes
	Dimensions (W x H x D)	17-1/8” x 6-3/4” x 14-1/2”; 435 x 171 x 368 mm
	Weight	23.8 lbs.; 10.8 kg
	ECO mode	Yes



Four-Year Manufacturer's Warranty

This item is features a four-year parts and labor warranty.
