Features:

• Wireless Presentation Gateway: Connect via WiFi to wirelessly cast content from device
• Bring Your Own Device: Cast from Windows and Mac computers or Android devices using KDPlay™ software and app. Cast from iOS devices with AirPlay. Chromebook not currently supported
• Smooth Video: Glitch-free AV experience due to optimizations for video content
• Multi-Presenter Mode: Up to four presenters may share content at same time with auto adjusting screen layout.
• Easy Connection: Up to 16 simultaneous devices may connect, with access always provided to new connecting devices and automatic disconnect of oldest non-casting devices in case of maximum being reached.
• KDPlay™ Flash Included: Software auto-launcher with USB and USB-C connections allows Additional KDPlay™ Flash sold separately
• 4K/UHD Source & Display: Supports incoming signals and outputs at 4K/UHD for optimal clarity of spreadsheets and data content
• Annotation and White Board: Screen overlay tools for real-time collaboration. Screen captures are downloaded by QR code or in web browser
• Extended Monitor: Feature enables dual display setups such as video conference and presentation content view on side-by-side panels
• WiFi Direct or LAN Connection: May act as the wireless access point, or may be accessed by devices via the connected network
• Content Preview: Collapsible dock on side of display provides preview thumbnail and name of devices casting via KDPlay app
• Touch Screen / Mouse Forwarding: Connect touchscreen or mouse USB to unit to point and click on casted device
• Moderator Management: Administrator may start & stop device casting via web control page
• Web GUI Administration: Access unit setup, moderator, and security tools on web browser through LAN
• Three-Level Security: Including casting / pairing pin and Device-type permission options, AES-256 + RSA-1024 encryption
• Simultaneous Secure Dual Network: Two network ports enable concurrent connection to Public and Private networks for ease of guest access without compromising security
• Video Resolution: Outputs 4K 3840x2160 @ 30fps or 60fps [4:2:0] 10.2Gbps, or 1920x1080p @ 60fps
• Audio De-embedding: Audio of the casted device is de-embedded at the unit's analog L/R audio connector for ease of integrating with audio amplification and mixing systems

Multi-Presenter Quad Mode

Specifications:

• HDMI output: 1x HDMI 19-pin female connector
• Video Output Resolution: 3840x2160@60Hz,3840x2160@30Hz, 1920x1080@60Hz
• Format Compliance: HDMI1.4/HDMI2.0
• Input Video Resolution:
• 1080P @ 60Hz KDPlay app
• 1080P @ 60Hz Airplay for IOS devices
• HDCP: HDCP1.4/HDCP2.2
• Analog Audio Output: 1x 3.5mm TRS female connector
• LAN ports: RJ45 x2：1000Mbps x1,100Mbps x1
• USB interface: USB3.0 x1, USB 2.0 x1,Type-C x1
• Multi-Presenter Windows: ≥4+14（4 main windows+14 thumbnail windows)
• Number of simultaneous connections: ≥16
• Data rate per Cast: Up to 1200Mbps
• Video Playback Frame Rate: 20-60 FPS
• Latency: ＜100ms,Min 20ms
• Wireless transmission protocol: WIFI IEEE 802.11 a/g/n/ac
• Frequency band: 2.4 GHz & 5 GHz
• WIFI Antenna: MIMO 2x2
• FCC Conformance: Part 15, Class B Digital Device, 2.412-2.462 GHz, 5.18-5.24 GHz, 5.745-5.845GHz WiFi Frequency Range
• Dimension (W x D x H): 165mm x 95mm x 24.5mm（including antenna： 165mm x 125mm x 24.5 mm)
• Weight: 0.4lbs（200g)
• Temperature: -4° ~ +140° F (-20° ~ +60° C)
• Humidity (Storage / Operating): 20%-90%（non-condensing)
• DC Power: 12V / POE
• POE standard: IEEE802.3af
• Power Consumption: 10W(MAX)
