Features:

• Digital Distribution: 1 HDMI Source to 8 HDMI Displays
• Ultra HD/4K Resolution: 4096x2160 or 3840x2160 30Hz at 4:4:4 and 60Hz at 4:4:4
• HDCP Licensing: Compliancy up to HDCP 2.2 and backward compliant
• 18 Gbps Bandwidth: High Speed / Performance for latest HDMI standards
• HDR10 (High Dynamic Range): More life-like images through a greater range of luminance levels
• 3D Ready: Capability to pass 3D stereoscopic signal formats
• Resolution Support: SD, HD, and VESA up to UHD/4K
• Deep Color Support: Up to UHD/4K 30Hz 4:4:4/12 bits or 60Hz 4:4:4/8 bit
• EDID Control: Internal library with 15 EDID handshakes in addition to native EDID data of output/display 1
• Full Buffer ™ System: Manages TMDS re-clocking / signal re-generation, HDCP source & display authentication, Hot Plug Management and EDID Control handshake
• Lossless Compressed Digital Audio: Dolby® TrueHD, Dolby® Digital Plus, DTS-HD Master Audio ™ and Dolby® Atmos
• Deep Color Support: Up to 12 Bit at UHD/4K 24/25/30Hz 4:4:4
• HDMI and HDCP Licensing: Fully licensed and compatible with HDCP 2.2 and HDMI
• I2C Communication: EDID and HDCP buffering from Display to Source
• CEC Disconnect: Prevents all device communication signals via CEC, ARC, and HDMI Ethernet channels

Specifications:

Technical:

• Input: HDMI Connector, Type A, 19 Pin Female
• Output (Each): HDMI Connector, Type A, 19 Pin Female
• Bandwidth: TMDS bandwidth 18 Gb/s
• Deep Color Support: Digital video formats in Deep Color Mode up to 12 bits/color
• DDC Communication: EDID and HDCP Bi-directional buffering from Display to Source
• KD-DA1x8 Power Supply: KD-PS5V4A, 5V/4A, 100-240VAC, 50-60Hz, Interchangeable head, screw-in connector

General:

• Regulation: CE, RoHS, WEEE
• Enclosure: Black Metal
• Product Dimensions: KD-DA1x8 - 10.75" x 4.01" x 0.67"
• Product Weight: KD-DA1x8 - 1.5 lb

What's in the box:

• Power Supply (qty 1) 5V/4A, 20W, wall type, model KDSP5V4ASC
• Mounting Brackets
