Features:

• HDMI Correction: Resolves common HDMI integration obstacles related to HDCP, EDID, Hot Plug Detection, and bandwidth
• Compress/Decompress: Pair units to compress and decompress 18Gbps video signals and extend via legacy 10.2Gbps cabling
• Boost Mode: High equalization option on HDMI input for repair of degraded incoming signals
• Cabling Extension: Works with HDMI cabling for extension of 4K/UHD signals with HDR10 up to 75 ft / 23m in or out. Maximum one active/directional HDMI cable may be used.
• 4K/UHD Support: 4096x2160 or 3840x2160 24/25/30/60hz at 4:4:4(up to 18Gbps bandwidth)
• HDR10 and Dolby Vision: More life-like images through a greater range of luminance levels
• HDCP2.2: Compliancy up to HDCP 2.2 and backward compliant
• Deep Color Support: Up to 4K/UHD 30Hz 4:4:4/12 bits or 60Hz 4:4:4/8 bit
• Low Profile: Super compact chassis size
• USB Powered: Low power consumption enables power from standard USB micro port
• Full Buffer System ™: Manages TMDS re-clocking / signal re-generation, HDCP source & display authentication, Hot Plug Management and EDID Control handshake
• Lossless Compressed Digital Audio: Dolby® TrueHD, Dolby® Digital Plus, DTS-HD Master Audio ™ and Dolby® Atmos
• Auto-EQ: Precise signal equalization applied to input and output signals automatically delivers best possible picture quality
• EDID Control: Internal library with 15 EDID handshakes including 4K with HDR in addition to native EDID data of output/display
• Forced HPD: Enables integrator to choose if active signal voltage is forced to connected input device
• CEC and ARC Pass-thru: Enables inter-device communication signals via CEC, ARC, and HDMI Ethernet channels

Specifications:

Technical:

• Input: HDMI Connector, Type A, 19 Pin Female
• Output: HDMI Connector, Type A, 19 Pin Female
• Bandwidth: TMDS bandwidth 18Gbps
• Deep Color Support: Digital video formats in Deep Color Mode up to 12 bits/color
• DDC Communication: EDID and HDCP Bi-directional buffering from Display to Source
• Power Supply: USB to micro USB cable (power adapter not included)

General:

• Regulation: CE, RoHS, WEEE, EAC
• Enclosure: Black metal
• Product Dimensions: 2.17" x 3.085" x 0.68"
• Product Weight: 4 oz
