Features:

• Digital Switching: 2 HDMI Sources to 1 HDMI Display
• Resolution Support: SD, HD, and VESA up to UHD/4K
• 18 Gbps Bandwidth: High Speed / Performance for latest HDMI standards
• HDR10 (High Dynamic Range): More life-like images through a greater range of luminance levels
• HDCP 2.2 and HDMI Licensing: Fully licensed and compatible with HDCP 2.2 and HDMI latest technologies
• Ultra HD/4K Support: 4096x2160 or 3840x2160 30Hz at 4:4:4 and 60Hz at 4:4:4
• 3D Ready: Capability to pass 3D stereoscopic signal formats
• EDID Control: Internal library with 16 default EDID configurations for each input, including native EDID data of Output/Display
• Full Buffer ™ System: Manages TMDS re-clocking / signal re-generation, HDCP source & display authentication, Hot Plug Management and EDID Control handshake
• Lossless Compressed Digital Audio: Dolby® TrueHD, Dolby® Digital Plus, Dolby® Atmos and DTS-HD Master Audio ™
• Deep Color Support: Up to 12 Bit at UHD/4K 24/25/30Hz 4:4:4
• I2C Communication: EDID and HDCP buffering from Display to Source
• Control: Front panel push buttons and LEDs, Optical IR
• CEC: Full Support
• Control System Support: Compass Control® Pro ready. Fully controllable by all IR supported control systems.

Specifications:

Technical:

• Input (Each): HDMI Connector, Type A, 19 Pin Female
• Output: HDMI Connector, Type A, 19 Pin Female
• Bandwidth: TMDS bandwidth 18 Gb/s
• DDC Signal (Data): Input DDC Signal - 5 Volts p-p (TTL)
• HDMI Video/Audio Signal: Input Video Signal - 1.2 Volts p-p
• Power Supply: KD-PS5V1ASC, 5V/1A, 100-240VAC, 50-60Hz, Interchangeable head, screw-in connector

General:

• Regulation: CE, RoHS, WEEE
• Enclosure: Black Metal
• Product Dimensions: KDS2X1 - 4.3" x 1.1" x 2.8"
• Product Weight: KDS2X1 - 0.5 lb

What's in the box:

• Power Supply (qty 1) 5V/1A, 5W, wall type, model KDSP5V1ASC
• Mounting Brackets
• IR Remote
