Klipsch Heresy IV 12" 3-Way Horn-Loaded Floorstanding Speaker RED OAK BLACK (Each)

The Klipsch Heresy IV is a compact three-way Heritage Series loudspeaker that combines high efficiency, horn-loaded midrange and high-frequency drivers, and a powerful 12" woofer. The fourth generation introduces a rear-firing Tractrix port for improved low-frequency extension while retaining the dynamic, highly efficient performance that has defined the Heresy since its introduction in 1957.

A K-702 midrange compression driver with a polyimide diaphragm is coupled to a K-704 Tractrix horn featuring Klipsch Mumps technology for consistent dispersion throughout the listening area. High frequencies are reproduced by a K-107-TI titanium-diaphragm compression driver, while a K-28-E 12" fiber-composite woofer and rear-firing Tractrix port provide strong, controlled bass performance.

Features:

• 3-Way Heritage Design - Combines a 12" woofer with horn-loaded midrange and high-frequency compression drivers.
• K-702 Midrange Compression Driver - Uses a 1.75" (4.45 cm) polyimide diaphragm for detailed and dynamic midrange reproduction.
• Tractrix Midrange Horn - K-704 horn incorporates Klipsch Mumps technology for improved coverage and dispersion.
• Titanium High-Frequency Driver - K-107-TI 1" (2.54 cm) titanium diaphragm compression driver provides detailed high-frequency reproduction.
• Wide-Dispersion Phase Plug - Helps provide more consistent high-frequency dispersion throughout the listening area.
• 12" Fiber-Composite Woofer - K-28-E woofer delivers powerful low-frequency performance.
• Rear-Firing Tractrix Port - Improves airflow and extends low-frequency performance compared with previous generations of the Heresy.
• 99 dB Sensitivity - High efficiency enables substantial output from relatively modest amplifier power.
• Premium Input Panel - Dual binding posts provide secure connections and support bi-wiring and bi-amping.
• Book-Matched Wood Veneer - Real wood veneer panels are arranged to provide a matched appearance.
• Slant Riser Base - Positions the loudspeaker at an upward angle for proper listening orientation when placed on the floor.
• Made in Hope, Arkansas - The enclosure is made in the USA using domestic and imported components.

Specifications:

Acoustic Performance:

• Speaker Type: 3-Way Horn-Loaded Loudspeaker
• Frequency Response (+/- 4 dB): 48 Hz - 20 kHz
• Sensitivity: 99 dB @ 2.83V / 1m
• Power Handling: 100W Continuous / 400W Peak
• Maximum SPL: 116 dB Continuous
• Nominal Impedance: 8 Ohms Compatible
• High-Frequency Crossover: 4.5 kHz
• Mid-Frequency Crossover: 850 Hz

Drivers:

• High-Frequency Driver: K-107-TI 1" (2.54 cm) Titanium Diaphragm Compression Driver
• High-Frequency Horn: K-79T Tractrix Horn
• Midrange Driver: K-702 1.75" (4.45 cm) Polyimide Diaphragm Compression Driver
• Midrange Horn: K-704 Tractrix Horn with Klipsch Mumps Technology
• Low-Frequency Driver: K-28-E 12" (30.48 cm) Fiber-Composite Cone Woofer
• Bass Loading: Rear-Firing Tractrix Port

Construction & Connections:

• Enclosure Material: MDF
• Finish: Red Oak
• Grille: Black
• Inputs: Dual Binding Posts
• Bi-Wire: Yes
• Bi-Amp: Yes
• Base: Slant Riser

Dimensions & Weight:

• Height: 24.81" (63 cm)
• Width: 15.93" (40.5 cm)
• Depth: 13.25" (33.7 cm)
• Weight: 45 lb (20.4 kg)
