Epson Home Cinema LS7500 4K HDR Short Throw Laser Projector

The Epson Home Cinema LS7500 is a 4K laser projector featuring a short throw Epson Cinema Lens for flexible large-screen home cinema installations. Its true laser diode array and 3-chip 3LCD projection system deliver 3,500 lumens of both colour and white brightness.

Epson 4K Display Technology produces a full 8.29-million-pixel on-screen image at 3840 x 2160. Full 10-bit colour processing supports HDR10 and HLG content, while a dynamic contrast ratio of up to and over 1,000,000:1 helps produce deeper shadow detail and greater distinction between bright and dark scenes.

The Short Throw Epson Cinema Lens uses a multi-element precision glass structure and a 1.0–1.3x manual optical zoom. Its 1.0–1.31 throw ratio allows the projector to sit approximately three feet closer to the wall than a standard throw projector, while supporting image sizes from 40" to 300". Manual lens shift of ±59% vertically and ±21% horizontally provides additional installation flexibility.

For gaming, the LS7500 supports refresh rates up to 120 Hz, Auto Low Latency Mode and input lag below 20 ms. Dual HDMI 2.1 connections support HDCP 2.3, with one HDMI input providing eARC/ARC audio passthrough. Built-in Bluetooth 6.0 also supports optional two-channel wireless audio streaming directly from HDMI input sources.

Features:

• Epson 4K Display Technology with 8.29 million pixels on screen
• True laser diode array light source
• 3-chip 3LCD projection technology
• 3,500 lumens colour brightness and 3,500 lumens white brightness
• Up to and over 1,000,000:1 dynamic contrast ratio
• Full 10-bit HDR colour processing
• HDR10 and HLG support
• Short Throw Epson Cinema Lens with multi-element precision glass structure
• 1.0–1.31 throw ratio
• Supports projected images from 40" to 300"
• Manual 1.0–1.3x optical zoom
• Manual vertical and horizontal lens shift
• Up to 120 Hz refresh rate
• Auto Low Latency Mode with input lag below 20 ms
• Dual HDMI 2.1 inputs with HDCP 2.3
• HDMI eARC/ARC support
• Built-in Bluetooth 6.0 wireless audio support
• Built-in Wi-Fi 6E for firmware updates
• RS-232C and 12V trigger connections for system integration
• Up to 20,000-hour laser light source life in Normal Mode
• Front-exiting airflow design for flexible installation

Specifications:

• Projection System: Epson 3LCD
• Chip Architecture: 3-Chip
• Light Source: True Laser Diode Array
• Driving Method: Poly-Silicon TFT Active Matrix, 0.62" Wide Panel
• Output Resolution: 3840 x 2160 using Epson 4K Display Technology
• Maximum Input Resolution: 4096 x 2160
• Supported Resolutions: 3840 x 2160, Full HD 1080p/i, HD 720p, 576p/i, 480p/i
• Native Aspect Ratio: 16:9 Widescreen
• Colour Brightness: 3,500 Lumens, IDMS Rated
• White Brightness: 3,500 Lumens, ISO Rated
• Dynamic Contrast Ratio: Up to and over 1,000,000:1
• Colour Reproduction: Up to 1.07 Billion Colours
• HDR: HDR10 & HLG
• HDR Colour Processing: Full 10-bit
• Colour Modes: Dynamic, Vivid, Cinema, Natural
• Projected Image Size: 40" – 300"
• Light Source Life: Up to 20,000 Hours in Normal Mode
• Lens: Short Throw Epson Cinema Lens, Multi-Element Precision Glass Structure
• Focus: Manual
• Optical Zoom: Manual, 1.0 – 1.3x
• Lens F-Number: 1.49 – 1.61
• Focal Length: 13.9 – 18.1 mm
• Throw Ratio: 1.0 – 1.31
• Vertical Lens Shift: -59% to +59%, Manual
• Horizontal Lens Shift: -21% to +21%, Manual
• Projection Methods: Front, Front-Ceiling, Rear, Rear-Ceiling
• Aspect Adjustment: Full, Super Zoom, Anamorphic Wide & Horizontal Squeeze
• Gaming: Up to 120 Hz, Auto Low Latency Mode, Input Lag Below 20 ms
• HDMI: 2 x HDMI 2.1 with HDCP 2.3; 1 Supporting eARC/ARC
• USB: 1 x USB Type-A 5V/2A Power, 1 x USB Type-A for Firmware Updates
• Service: 1 x Mini USB
• Audio Output: 1 x 3.5 mm Mini Plug
• Network: 1 x RJ45 LAN for Projector Control
• Control: 1 x RS-232C D-Sub 9-Pin
• Trigger Output: 12V DC, 200mA Maximum
• Wireless LAN: Built-In Wi-Fi 6E for Firmware Updates Only
• Bluetooth: Built-In Bluetooth 6.0
• Bluetooth Profiles: A2DP, AVRCP & aptX
• Fan Noise: 22 – 25 dB
• Power Consumption: 330W Normal / 217W Quiet
• Power Supply: 100–240V AC ±10%, 50/60 Hz
• Operating Temperature: 41–95°F (5–35°C)
• Dimensions (W x D x H, Including Feet): 17.3 x 13.1 x 6.3" (439.4 x 332.7 x 160.0 mm)
• Weight: 18.2 lb (8.3 kg)
• Colour: White
• Model: Home Cinema LS7500
• Product Code: V11HC36020
• Country of Origin: Philippines

What's in the Box:

• Epson Home Cinema LS7500 Projector
• Power Cable
• Remote Control
• 2 x AA Remote Control Batteries
• Quick Start Guide
