The Denon AVR-1612 5.1 Home Theater Receiver delivers exceptional performance and convenient features in a home theater centerpiece. Offering the latest inputs, this powerful receiver features advanced processing that brings out the best in your Blu-ray/DVD players, game consoles, and other entertainment devices. The AVR-1612 supports high-resolution audio formats, including Dolby TrueHD and DTS-HD, for a dynamic surround-sound listening experience. It also supports HDMI 1.4a, allowing you to get the most out of 3D content. Enhanced by direct digital connectivity for iPhone/iPad/iPod via the front panel USB, and including an optional networking dock connectivity option for iPod and iPhone, the AVR-1612 offers an exceptional foundation for your home theater system.

Premium Audio Technologies for Superb Surround Sound
Fully compatible with current HD audio formats, the Denon AVR-1612 5.1-Channel A/V Receiver provides powerful, theater-quality surround sound. It ensures maximum audio performance with multiple technologies:

• Equal Power Amp Design: Each of the AVR-1612's five 120-watt channels is powered by its own discrete circuit. This allows the receiver to reproduce original sound more faithfully than conventional models, which use integrated circuits.

• High-Definition Audio Support: The AVR-1612 features support for Blu-ray high-definition audio formats, including Dolby TrueHD and DTS-HD Master Audio. These formats play back sound with exceptional fidelity, providing a more realistic listening experience.

• Dolby Pro Logic IIz:Providing two additional height channels, this feature adds a vertical dimension to the soundstage, providing more immersive surround sound (with an optional, external amplifier).

• Audyssey MultEQ Support: Audyssey technology helps create an optimal acoustic profile for your home theater. Using a microphone, Audyssey MultEQ measures sound levels and adjusts speaker configuration accordingly, making setup fast and easy.

Full HD Support
With four HDMI inputs, the AVR-1612 allows you to route multiple high-definition devices--like game consoles and Blu-ray players--to your TV.

Vivid 3D Visuals with HDMI 1.4a
The AVR-1612 comes equipped with HDMI 1.4a, allowing you to make the most of several premium video features:

• 3D Pass-Through: With the advent of 3D media, it is important to own a receiver that recognizes 3D video signals. The AVR-1612 is able to pass through 3D signals from your Blu-ray player, ensuring that the 3D effect doesn't get lost in translation. It also recognizes signals from 3D television broadcasts.

• Audio Return Channel: HDMI 1.4a also features an Audio Return Channel, which allows both audio and video content to be sent through a single HDMI cable. This eliminates the need for separate audio and video cables running from your TV to the receiver.

• Deep Color and x.v.Color Support: The AVR-1612 also supports Deep Color and x.v.Color content, which can display a larger color range than standard-definition schemes. The result is a more lifelike, vibrant picture.

iPod Connectivity
With a built-in USB port, the AVR-1612 supports digital music playback from an iPod, iPhone, iPad, or USB drive. The receiver can also be used with the Denon Networked Control Dock (sold separately) for network streaming or docking your iPod/iPhone. A compressed audio restorer guarantees that standard MP3 playback is crisp and clear.

GUI Overlay and Remote Control for Simple Operation
With its programmable functions and intuitive button layout, the AVR-1612 is designed for ease of use. The front panel is smartly organized, featuring clearly labeled buttons and onboard controls for volume and source. In addition, its on-screen display provides quick information about your system's settings.

The AVR-1612's simple remote control is easy to use, giving you more flexibility in controlling your home theater.

Product Information
The receiver measures 6-3/8 by 17-1/8 by 15-3/64 inches (H x W x D), and weighs 20-1/2 pounds.

What's in the Box
AVR-1612 5.1-Channel A/V Receiver, remote control, AA batteries, setup microphone, AM loop antenna, FM indoor antenna, and owner's manual.

GENERAL

• Finish Black - YES
• Equal Power Amplifiers Y/5 ch - YES
• Power Output; Watts Per Channel 75 - YES
• All Channels Rated @ 0.05 THD - NO
• All Channels Rated @ 0.08 THD - YES
• THX Ultra2-Certified - NO
• Low Impedance Drive Capability - YES
• High-Current/Discrete Amplifiers - YES
• dlna 1.5 Certified - NO
• Windows 7 Certified - NO
• Apple AirPlay Certified - NO
• Made for iPod/Works with iPhone Certified - NO
• RadioDenon.com - access to over 12,000 Internet Radio Stations - NO
• Flickr Photo Streamming - NO
• Napster - NO
• Microprocessor User Re-set - YES
• Detachable Power Cord - NO
• Pre-programmed Remote Control - YES
• Low Power Consumption in Standby Mode (0.1w) - YES
• Interactive Owners Manual on CD-R - YES
• Weight: In Pounds 20.2 - YES
• Width (inches) 17.1 - YES
• Height (inches) 6.4 - YES
• Depth (inches) 15 - YES

CONNECTIVITY

• Digital Inputs: Coaxial 1 - YES
• Digital Inputs: Optical 1 - YES
• Digital Input – DENON Link 4 - NO
• True 24-bit/96-kHz Digital Input Capability - YES
• True 24-bit/192-kHz Digital Input Capability (Denon Link) - NO
• Assignable Digital Inputs - YES
• Digital Outputs: Optical - NO
• Digital to Analog REC Out - NO
• Analog Audio Inputs, Incl. Tuner 5 - YES
• HD Radio Tuner - NO
• Phono Input - NO
• Analog Record Outputs - NO
• HDMI Video Inputs – v1.4a Supports 3D and Audio Return Channel 4 - YES
• HDMI Video Outputs 1 - YES
• HDMI Audio/Video Repeater Function - YES
• HDMI Video Switching Function - YES
• HDMI Deep Color Support-36Bit - YES
• HDMI xvYCC Color Space Support - YES
• HDMI SACD Support - NO
• Composite Video Inputs 3 Incl. Front - YES
• Composite Video Outputs 1 - YES
• S-Video Inputs 1 x Dock - YES
• S-Video Outputs - NO
• Component Video Inputs x Bandwidth - *Assignable - NO
• Component Video Outputs - NO
• Front Panel A/V Inputs w/Cover * Composite - YES
• RJ-45 Etherent Port - IP Control and Network Audio/Photo Streaming - NO
• RS-232 Port – Third Party Remote Controllers - NO
• PC Setup and Control Capability - NO
• IR Serial Remote In/Out terminals - NO
• +12v Trigger Output - Assignable - NO
• Sirius Satellite Radio – with optional antenna - NO
• Pre-amp Outputs for Multi-Zone - NO
• High Pass Filter for Multi-Zone Outputs - NO
• Multi-Zone Pre-Amp Outputs – Selectable Output Levels - NO
• Discrete Multi-Zone Composite Video Output - *S-Video also - NO
• Main Zone Pre-Amp Outputs Sub - YES
• iPod Dock Control Port (Using optional ASD-11R DOCK) - YES
• USB Audio Port iPod Direct/Flash/HDD - YES
• XLR Analog Input - NO
• XLR Analog Output - NO
• 6-Ch. External Analog Input - NO
• 8-Ch. External Analog Input - NO

CONVENIENCE FEATURES

• iPhone App Control - NO
• Auto Setup Calibration - YES
• Input Delete Function - YES
• Auto/Manual Room Equalization - YES
• Audyssey MultEQ Room Equalization YES/MultEQ - YES
• Audyssey Pro Calibration Ready - NO
• Audyssey Dynamic Volume - YES
• Audyssey Dynamic EQ - YES
• Auto Setup Microphone Included/Type Y - YES
• Variable High/Low Pass Crossover Points (12/24dB) - 40/60/80/100/ 120/150/200/250 - YES
• Source Function Renaming - NO
• Video Conversion –Composite to S-Video to Component - NO
• Video Conversion – Analog to HDMI - NO
• Video Scaling - NO
• Dual Surround Mode Spkr. Selector - NO
• Icon-Based Graphical User Interface with video overlay on 1080p HDMI output - YES
• Personal Memory Plus - YES
• Party Mode Plus - NO
• Audio Signal Delay (Sync. Audio with Video signal) – By source - YES
• Auto Surround Mode (Analog or Digital Input Type) - YES
• 56 Station Auto-Preset Memory Tuning - YES
• Radio Data System (RDS) - NO
• Direct Function (Tone Bypass) - YES
• Volume Control Un-muting - YES
• Video Select Control - NO
• Multi-Source/Multi-Zone - NO
• Discrete Remote Power On/Off, Source Selection and Volume for Main and Second/Third* Zones Main Only - YES
• Assignable Amplifier Configuration of Surround Back Channels - NO
• Speaker Time-Delay and Level Controls: L/R, Sub, C, Surr. L/R, Surround Back - YES
• Relay-Controlled Protection Circuits - YES
• Pre Labled Assignable Digital Inputs - YES
• Digital to Analog Conversion Multi Zone Outputs - NO

COMPONENT TECHNOLOGY

• Dynamic Discrete Surround Circuit – D.D.S.C - HD - NO
• Dolby Digital, dts and DSP Modes – Analog Devices, HammerHead SHARC - YES
• Processor(s) – Bit Depth and Type ADSP21487 x 1 32-bit Floating Point - YES
• AL24 Processing - NO
• 24-bit/192-kHz DACs AKM Semiconductor 24-bit/192-kHz AK4358VQ x 2 per channel differential - YES
• Analog-to-Digital Conversion - Bit Depth/Sampling Rate 24-bit/192-kHz AK5358B - YES
• Analog DevicesFull 12-bit Input/Output Video Processing/Scaling - NO
• Analog Devices Noise Shaped Video (NSV) - NO
• Independent Power Supplies - YES
• Pure Audio Construction - NO
• Toroidal Power Transformer - NO
• Banana Plug Speaker Terminals, All Channels - YES

SOUND MODES

• Dolby Pro Logic IIx – with Cinema, Music, Game Modes - NO
• HDCD Decoder - NO
• Dolby TrueHD and Dolby Digital+ Decoding - YES
• Dolby Digital Surround EX Decoding - YES
• dts-HD Master Audio and High Resolution Decoding - YES
• dts ES Discrete 6.1 Decoding - YES
• dts ES Matrix 6.1 Decoding - YES
• dts Neo:6 Stereo-to-Surround Cinema and Music Mode - YES
• dts 96/24 5.1 for DVD-Video Processing - YES
• Dolby Headphone - NO
• THX Post-Processing – DPL (4.0), DPL2 Cinema, DD/DTS (5.1), ES Discrete (6.1), ES Matrix, Neo:6 Cinema - NO
• THX Ultra2 7.1 Cinema, Music and Game Modes - NO
• THX Surround EX Decoding - NO
• Audyssey Dynamic Surround Expansion (DSX) Processing - NO
• Pure Direct/Direct/Stereo Modes on Digital/Analog inputs - NO
• Stereo/Direct Modes w/Pure Analog Path - YES
• Multi-Channel Stereo Mode - YES
• Video Game Mode - YES
• Wide Screen 7.1 Mode - NO
• Mono Movie Surround Mode - YES
• Rock Arena Surround Mode - YES
• Matrix Surround Mode - YES
• Jazz Club Surround Mode - YES
• Virtual Surround Mode – For 2 Speakers/Headphones - YES

One-Year Manufacturer's Warranty
