Key Digital KDX2X1WVTX 2x1 4K Wall Plate Switcher HDMI & DisplayPort
Brand New · Factory Sealed · Key Digital Authorized Dealer
$889.99
Free Canada-wide Shipping
•
Ships in 2 to 4 Days
end of _buybox_shipping
end of _buybox_core
end of _payments
end of _buybox_couponend of _xwarranty
- Available
- Free shipping
- 1yr Manufacturer Warranty
- 5% Price Promise
Trusted by 150,000+ Canadian customers since 2001
Features:
- Presentation Switching: 1 HDMI and 1 Display Port / VGA with Analog Audio source selected by push button
- Rx Options: Native integration with KD-X40MRx black box HDBaseT Rx and KD-PS42 Presentation Switcher. Other Rx options available
- Ultra HD/4K: Supports up to 4096x2160 or 3840x2160 24/25/30/60hz at 4:4:4 (signals up to 18Gbps bandwidth)
- Auto-Sensing: Automatic selection of newly detected source and switching from newly disconnected source when enabled
- Converts (KD-X2x1WVTx only): VGA video and analog audio to HDMI
- Video Scaling (KD-X2x1WVTx only): Aspect ratio, resolution set, image size, image position, image phase, and color tone processing of VGA signals ensures proper display
- HDCP Licensing: Fully licensed and compatible with HDCP 2.2
- HDR10: More life-like images through a greater range of luminance levels
- Power Over HDBaseT: Wall-plate unit powered by Rx/Presentation Switch unit
- Installation: Tx unit designed for installation in standard US dual-gang box. Silver Decora plate included
- Signal Extension: For resolution and cable quality
- 4K/UHD (18G): Up to 40m / 131ft
- 1080p: Up to 70m / 230ft
- Deep Color Support: Up to UHD/4K 60Hz 4:2:0 12bits or 4:2:2 12bits
- Full Buffer System ™: Manages TMDS re-clocking / signal re-generation, HDCP authentication to source & display, EDID Control handshake, and Hot Plug Detection Voltage
- EDID Management: Internal library with 15 internal EDID handshakes including 4K with HDR in addition to native EDID data copied from the Rx display/device
- VGA EDID (KD-X2x1WVTX only): Unique EDID handshake provided to VGA source and HDMI source
- IR Sensor: Wall-plate collects line-of-sight IR from remote(s) without external IR wiring
- RS-232: Bi-Directional control to/from Tx and Rx/Presentation Switch unit
- Unit Control: via USB for initial installation steps
- Lossless Compressed Digital Audio: Dolby® TrueHD, Dolby® Digital Plus, DTS-HD Master Audio ™, and Dolby® Atmos
Specifications:
Technical:
- KD-X2x1WDTx Inputs: 1 HDMI, 1 Display Port, 1 IR Sensor, 1 Serial IR
- KD-X2x1WVTx Inputs: 1 HDMI, 1 DB15, 1 3.5mm Stereo Audio, 1 IR Sensor, 1 Serial IR
- Outputs: 1 CAT5e/6 UTP/STP, 1 Bi-Directional RS-232
- DDC Signal (Data): Input DDC Signal: 5 Volts p-p (TTL)
- KD-X2x1WVTx VGA Video Signal: Input Video Signal: 1.2 Volts p-p
- KD-X2x1WVTx Analog Audio Input: 2 VRMS line audio, 3.5mm Stereo Female
- KD-X2x1WDTX Display Port Video/Audio Signal: Input Video Signal: 1.2 Volts p-p
- HDMI Connector: Type A, 19 Pin Female
- KD-X2x1WVTx VGA Connector: 15 Pin, Female
- KD-X2x1WDTx Display Port Connector: Full Size, 20 Pin Female
- RJ45 Connector: Shielded Link Connector, HDBaseT
- IR Connectors: 1 IR Sensor, 1 2-pin phoenix terminal
- RS-232 Connector: 3-pin phoenix terminal
General:
- Regulation: CE, RoHS, WEEE, EAC
- Enclosure: Tx unit: Brushed aluminum face with black metal backing
- Dimensions: 3.21" x 2.06" x 0.787" (Wall-plate)
- Product Weight: 0.7 lbs
What's in the box:
- Aluminum Decora plate (qty 1)
- Decora mounting screws with flat head (qty 4)
- Gang-box mounting screws (qty 4)
- Mounting bracket (qty 2)
- 3-pin phoenix terminal (qty 1)
- 2-pin phoenix terminal (qty 1)
