Connect and share wirelessly for double the fun

Connect your TV and Soundbar easily through Bluetooth with TV Sound Connect.* The absence of trailing wires between the Soundbar and TV allows you to showcase the slim and sleek design of both systems, while maintaining a clean look in your living environment. Easily control the Soundbar and TV from a single TV remote.**

*Only compatible with certain Samsung devices. For a complete list of devices please visit www.samsung.com/*****.
**TV remote controls Soundbar Volume and Power only.

Convenient app for easy control

Control your Soundbar in the palm of your hand with the Samsung Audio Remote App*. This convenient app is a control hub for basic controls like power, volume, and media controls, as well as custom settings like 7-band EQ. You can also easily select the source, and choose from an array of sound effects like Music Mode, Cinema Mode, and Sports Mode. Automatic pairing connects the app from your mobile device to your Soundbar via Bluetooth for simple and easy audio control.

*Available only for Samsung mobile devices running Android OS.

More accurate and clearer sound with dedicated amplifiers

Equipped with advanced audio technology, the Samsung Soundbar offers exceptionally balanced sound. Unlike most sound systems, it uses separate amplifiers to process high, mid and low frequencies, as opposed to using only one amplifier. This results in frequencies that are better tuned, so you can enjoy much more accurate audio across the entire spectrum of sound.

Specifications:

General

• Total Power: 320 W
• Number of Channel: 2.1 Ch

Speaker

• Speaker Type: Vented Enclosure
• Subwoofer Type ( Active / Passive / Wireless, Bulit-in ): Wireless
• Subwoofer Enclosure Type: Bass Reflex
• Subwoofer Driver Size: 7"

Audio

• Amp Type: Digital Amp
• Crystal Amplifier: Yes
• Dolby Digital: Dolby 2ch
• DTS Digital Surround: DTS 2ch
• Bluetooth HI-FI Codec: Yes
• Surround Mode: Surround Sound Expansion
• Night Mode: Yes
• Number of Sound Modes (DSP): 4
• Sound Modes (DSP) Type: Music, Voice, Sports, Cinema

Video

• 3D Video Pass: Yes

Decoding Format

• AAC: Yes
• MP3: Yes
• WAV: Yes
• WMA: Yes
• OGG: Yes
• FLAC: Yes

Connectivity

• Anynet+ (HDMI-CEC): Yes
• USB Host: Yes
• Bluetooth: Yes
• TV SoundConnect: Yes
• ARC (Audio Return Channel): Yes
• Bluetooth Power On: Yes
• Number of HDMI Input/Output: 1 / 1
• Number of Audio Input: 1
• Number of Optical Input: 1
• Auto Power Link: Yes

Special Feature

• BT App: Yes

Dimension

• Packing Type: One Packing
• Net Dimension (Main Speaker) (WxHxD): 943.5 x 56 x 65.5 mm
• Net Dimension (Sub Woofer) (WxHxD): 452 x 335 x 154 mm
• Gross Dimension (WxHxD): One Packing: 1000 x 480 x 206 mm

Weight

• Net Weight (Main Speaker): 1.7 kg
• Net Weight (Sub Woofer): 6.8 kg
• Gross Weight (One Packing): 10.7 kg

Power

• Stand-by Power Consumption (Main): 0.45 W
• Stand-by Power Consumption (Subwoofer): 0.45 W
• Operating Power Consumption (Main): 25 W
• Free Voltage: Yes
• Operating Power Consumption (Subwoofer): 28 W
• Energy Star: Yes

Accessory

• Remote Controller: Yes
• Optical Cable: Yes
• Wall Mount Bracket: Yes
• Battery: Yes
