TOA YW-1022 Y Infrared Antenna Distributor

Secure One-Page Checkout

$189.99

Get 8 Miles When you spend $189.99. See details
TOA Authorised
This product is brand-new and factory sealed TOA YW-1022 Y  Special Order 189.99
UPC : TBD   5% Price Promise
Warranty : 1yr Manufacturer Special Order Return Policy
Shipping : FREE in Canada Shipped when Received



To purchase now by phone, call toll-free: 1-888-248-4969. Item: 6533

$63/mo suggested payments with 3 month special financing now with Flexiti.Get Instantly approved for 0% financing


Distributor

The YW-1022 is a distributor that can work in the frequency range of 1.6 to 1000 MHz ( except 50 to 70 MHz). Power passing type permits easy power supply.

Specifications:

  • Frequency Range: 1.6 – 1000 MHz ( excluding 50 – 70 MHz)
  • Distribution Loss: 4.5 dB ±3 dB ( between the Mixing and each Distribution terminals)
  • Input/Output Impedance: 75 U
  • Coaxial Connector: Mixing terminal: BNC jack, power passing type ( 30 V DC or less, 2 A or less), Distribution 1 and 2 terminals: BNC jack, power passing type ( 30 V DC or less, 1 A or less)
  • Operating Temperature: –10 °C to +50 °C
  • Finish: ABS resin, gray
  • Dimensions: 75 (W) x 122 (H) x 34 (D) mm
  • Weight: 105 g
  • Accessory: Unit fixing wood screw ( 4.1 x 25 ) -.2

TOA YW-1022 Y Infrared Antenna Distributor
