High-End Home Theater Performance Starts Here

This Onkyo network receiver is a winner in three areas. Firstly, its video performance is unrivalled. An HQV® Vida™ VHD1900 processor upscales content to 1080p, with Qdeo™ technology taking full HD out to an eye-popping 4K. An ISF system calibrates video from all inputs to industry standards, and the resulting picture is spectacular. Secondly, audio performance is unmatched, as proven by THX® Select2 Plus™

certification. The receiver delivers power effortlessly through three-stage inverted Darlington circuitry and 192 kHz/24-bit DACs. Finally, you get more setup flexibility. There are eight HDMI® inputs—including an MHL for smart phones—and two outputs. Two USB ports connect iPod®/iPhone® and LAN adaptor, enabling wireless PC and online audio. Three mind-blowing sound expansion systems are included—Audyssey DSX®, DTS Neo:X™, and Dolby® Pro Logic® IIz—assisted by Audyssey MultEQ XT32 room correction. Digital crossover processing, front channel bi-amping capability, and three-zone audio distribution grant the freedom to customize. With new InstaPrevue™ input selection technology and intuitive system control via iPhone and Android phone, now is the time to upgrade to an Onkyo.

Special Features

8in/2out HDMI Support for 3D Video and Audio Return Channel
THX Select2 Plus Certified
Network Capability Delivers Internet Radio and Network Streaming
Dual Core Video Engine w/ HQV Vida and Marvell Qdeo™ Processing
MHL™ (Mobile High-Definition Link) for Smart Phone Content on HDTV
Picture-in-Picture Input Source Preview with InstaPrevue™ Technology
Direct Digital Connection of iPod/iPhone via Front-Panel USB Port
Onkyo Remote App for iPod/iPhone
DTS Neo:X, Dolby® Pro Logic® IIz and Audyssey DSX Add New Dimensions to Surround Sound
Hybrid Standby Function to Reduce Power Consumption

Amplifier
# Channels	7.2
Power Watts/ch	135W (8ohms 20-20kHz, 0.08%, 2 Channels Driven, FTC)
Power (8ohms 20-20kHz 0.05%) /Ch	NO
THX Certified	Select2 Plus
Continuous 6ohms Rated	YES
Certified 4ohms performance	YES
All Discrete Circuitry	YES
3-Stage Inverted Darlington Circuitry	YES
PUSH-PULL Design	NO
Independent Block Construction (Amp/Preprocessor)	YES
Toroidal Transformer	NO
Independent Power Supply	NO
Bi-amp Capability For Front	YES
BTL Capability For Front	NO
Digital Crossover Processing Network	NO
Processing
DOLBY Decoder	True HD, DD Plus, PLIIz
DTS Decoder	DTS-HD Master Audio, DTS-HD Express
Dolby PLIIz	YES
ONKYO GAME Surround Modes	YES
THX Processing Mode	YES
Audyssey DSX	YES
Audyssey Dynamic EQ	YES
Audyssey Dynamic Volume	YES
Direct/Pure Mode	YES / NO
Music Optimizer	YES (Advanced)
192K/24 Bit DACs	YES (Burr-Brown)
VLSC	NO
isf Certified Calibration Control	YES
Connectivity
Audio I/O	7 / 1
Phono Input	YES
Digital Audio IN (OPT/COAX)	2 / 3
Digital Audio OUT (OPT/COAX)	NO
Composite I/O	5 / 1
S-Video I/O	NO / NO
Component Video I/O	2 / 1
Front-Panel A/V	V
Front-Panel Optical	NO
USB Input	Front (made for iPod/iPhone) and Rear
HDMI I/O	8 (7 + 1)/ 2
HDMI Version	V1.4a (supports 3D video and Audio Return Channel)
Component Video Upconversion	NO
Analog To HDMI Upconversion	YES
1080p Upscaling	YES (Marvell Qdeo)
4K (up to 4096 x 2160) Upscaling	YES (Marvell Qdeo)
Multi-Channel Input	NO
Analog Pre-Outs	9.2
Speaker A/+B	NO
Powered Zone2	YES
Powered Zone3	YES
Zone 2 Line Out	YES
Zone 2 Video Out	NO
Zone 3 Line Out	YES
U-Port	NO
iPod Ready	YES (direct USB input)
HD Radio Ready	NO
Internet Radio Capable	YES (vTuner, Pandora, Spotify, Rhapsody, Sirius/XM iRadio, Slacker, LastFM iRadio, Aupeo, MP3tunes)
Streaming Audio From PC	YES
Streaming Audio From USB memory	YES
Wireless Network Ready via USB	YES (optional UWF-1)
PC Input (15 pin D-sub)	YES
Integration Access
RS-232	YES
IR Input	YES
Ethernet	YES
ONKYO-RI System Control	YES
12V Trigger	YES (zone 2/3)
Miscellaneous
Pre-Pro/Learning Remote	YES / YES
Back-Lit Remote	NO
On Screen Remote Programming	YES
Bi-directional Remote Setup via GUI	YES
Activity Based Remote	YES
Color-Coded Speaker Terminals	YES
Auto Speaker Calibration W/Mic.	YES (Audyssey MultiEQXT32)
OSD Out	YES (advanced "Home" GUI)
Solid Aluminum Front	NO
Warranty	2 YEARS

Amplifier Section
Power Output	-
All Channels	135 W (8 ohms, 20 Hz-20 kHz, 0.08%, 2 channels driven, FTC)
Front L/R	135 W (8 ohms, 20 Hz-20 kHz, 0.08%, 2 channels driven, FTC) 125 W + 125 W (6 ohms, 1 kHz, 0.7%, 2 channels driven, FTC)
Center	135 W (8 ohms, 20 Hz-20 kHz, 0.08%, 2 channels driven, FTC) 125 W + 125 W (6 ohms, 1 kHz, 0.7%, 2 channels driven, FTC)
Surround L/R	135 W (8 ohms, 20 Hz-20 kHz, 0.08%, 2 channels driven, FTC) 125 W + 125 W (6 ohms, 1 kHz, 0.7%, 2 channels driven, FTC)
Surround Back L/R	135 W (8 ohms, 20 Hz-20 kHz, 0.08%, 2 channels driven, FTC) 125 W + 125 W (6 ohms, 1 kHz, 0.7%, 2 channels driven, FTC)
Dynamic Power	300 W (3 ohms, 1 ch) 250 W (4 ohms, 1 ch) 150 W (8 ohms, 1 ch)
THD+N (Total Harmonic Distortion + Noise)	0.08% (20 Hz-20 kHz, Rated power)
Damping Factor	60 (Front, 1 kHz, 8 ohms)
Input Sensitivity and Impedance	200 mV/47 k-ohms (Line) 2.5 mV/47 k-ohms (Phono MM)
Output Level and Impedance	200 mV/470 ohms (Line out)
Phono Overload	70 mV (MM, 1 kHz, 0.5%)
Frequency Response	5 Hz-100 kHz/+1 dB, -3 dB (DSP bypass)
Tone Control	±10 dB, 50 Hz (Bass) ±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio	110 dB (Line, IHF-A) 80 dB (Phono MM, IHF-A)
Speaker Impedance	4 Ohms–16 Ohms or 6 Ohms–16 Ohms
Video Section
Input Sensitivity/Output Level and Impedance	-
Video	1 Vp-p/75 ohms (Component) 0.7 Vp-p/75 ohms (Component PB/CB, PR/CR) 1 Vp-p/75 ohms (Composite)
Component Video Frequency Response	5 Hz–100 MHz, -3dB
Tuner Section
Tuning Frequency Range	-
FM	87.5 MHz–107.9 MHz
AM	530 kHz–1,710 kHz
FM/AM Preset Memory	40 stations
General
Power Supply	AC 120 V, 60 Hz
Power Consumption	8.1A
Standby Power Consumption	0.1W
Dimensions (W x H x D)	17 1/8" x 7 13/16" x 17 1/8" (435 x 198.5 x 435.5 mm)
40.3 lbs (18.3 kg)

Description image for Onkyo TX-NR818 7.2 Channel Network AV Receiver

Two-Year Manufacturer's Warranty

This item is features a two-year parts and labor warranty.
